Page 24 - Application Guide INNOV@-0907
DHW/ZDC/DHW/ZUC
0060 0080 0100 0110 0130 0160 0190 0205
400/3ph/50Hz+N
[ m3/h ] 1785 2150 3530 3530 3470 5115 4990 4990
[ kW ] 6.59 8.48 10.70 12.15 14.21 17.98 20.86 21.50
[ kW ] 1.25 1.61 1.92 2.21 2.77 3.46 4.07 4.73
[ kW ] 5.66 7.16 9.04 10.27 12.00 14.90 17.55 19.02
[ kW ] 1.65 2.17 2.60 2.99 3.70 4.63 5.35 6.11
(1)
[V-ph-Hz] 400/ 3+N /50
[ A ] 2.9 3.7 4.48 5.13 6.16 8.01 8.66 11.35
[ A ] 5 6 7 7 10 13 14 15
[ A ] 24 32 40 46 50 66 74 101
[l] 1 1 1.1 1.1 1.36 1.95 1.65 1.65
[m2] 0.29 0.29 0.48 0.48 0.48 0.66 0.66 0.66
25 x 21,65 25 x 21,65 25 x 21,65 25 x 21,65 25 x 21,65 25 x 21,65 25 x 21,65 25 x 21,65
[ - ] 3 4 3 3 4 3 4 4
[ - ] (2)
[ mm ] 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.8
[ - ] 1.00 1.00 1.00 1.00 0.96 0.98 0.98 0.96
(3)
1 1 2 2 2 2 2 2
[ A ] 1.2 1.6 3.2 3.2 3.2 3.8 3.8 3.8
[W] 173 282 563 563 563 668 668 668
[Pa] 20 20 20 20 20 20 20 20
[Pa] 200 190 220 205 185 108 118 118
G3 G3 G3 G3 G3 G3 G3 G3
[m2] 2.2 2.2 3.6 3.6 3.6 5.0 5.0 5.0
1 1 1 1 1 1 1 1
[kW] 1.6 1.6 3.2 3.2 3.2 3.2 3.2 3.2
1 1 2 2 2 2 2 2
[ - ] (4)
[ kW] 5.5 6.3 10.2 10.79 11.7 16.9 18.0 19.2
[m2] 0.23 0.23 0.39 0.39 0.39 0.55 0.55 0.55
[ kW] 4.1 4.9 7.4 7.9 8.6 11.8 12.6 13.3
[m2] 0.23 0.23 0.39 0.39 0.39 0.55 0.55 0.55
[m3/h] 0.643 0.872 1.036 1.163 1.499 1.847 2.166 2.290
[ kPa ] 3.6 6 12 14 23 43 57 62
[ kPa ] 10 10 10 10 10 13 18 20
[ dm3] 0.547 0.547 0.939 0.920 0.920 1.312 1.312 1.312
[ kg/h ] 2.80 3.17 4.45 5.22 5.01 10.09 6.90 6.50
[ kg/h ] 3 3 3 3 3 3 3 3
[ kW ] 2.25 2.25 2.25 2.25 2.25 2.25 2.25 2.25
[mm] 1875 1875 1875 1875 1875 1875 1875 1875
[mm] 600 600 900 900 900 1200 1200 1200
[mm] 449 449 449 449 449 449 449 449
[dB(A)] 46 48 48 49 51 52 53 53
[kg] 162 169 207 232 265 273 285 287
TECHNICAL DATA
Tab.7 - Technical Data for water Cooled DX Units - DHW/ZDC/DHW/ZUC
Unit power supply
Air Flow
DHZ - T water 15°C / 30°C
Cooling Capacity
Power consumption
DHW - T water 40°C / 45°C (30% e.g.)
Cooling Capacity
Power consumption
Compressor
Type
Power supply
Nominal Current
FLA
LRA
POE Oil charge
Finned coil evaporator
Front Surface
Geometry
Rows
Type of ns
Fin piDHCh
SHR
Indoor fan
Type
Number of fans
Fans absorbed current
Fans absorbed power
AESP
AESP (maximum speed)
Air Filter
Filtration
Overall surface
Fire resistance class
Electrical heaters
Total Heating Capacity
N° of heaters
Material
Hot gas Reheating Coil
Heating capacity
Front Surface
Hot Water reheating coil
Heat. capacity@45/40°water T
Front Surface
Water ow
Water side pressure drop
Water valve pressure drop
Internal volume
Humidier
Max theoretical capacity
Effective capacity
Absorbed power
Frame
H
L
D
Sound pressure level**
Weight
