Application Guide INNOV@-0907- Page 25
DHW/ZDC/DHW/ZUC
0201 0251 0261 0271 0301 0401
400/3ph/50Hz+N
[ m3/h ] 7280 7280 7280 12950 12950 12950
[ kW ] 24.00 25.30 30.50 30.50 35.40 46.50
[ kW ] 4.76 4.99 5.95 5.95 6.85 9.15
[ kW ] 19.97 21.06 25.37 25.37 29.45 39.16
[ kW ] 6.36 6.67 8.03 8.03 9.27 12.27
(1)
[V-ph-Hz] 400/3/50 400/3/50 400/3/50 400/3/50 400/3/50 400/3/50
[ A ] 10.7 11.3 13.7 13.7 15.8 19.0
[ A ] 17 17 20 20 29 29
[ A ] 86 98 130 130 130 135
[l] 3.25 3.25 3.25 3.25 3.25 3.3
[m2] 0.8 0.8 0.8 1.3 1.3 1.3
25 x 21,65 25 x 21,65 25 x 21,65 25 x 21,65 25 x 21,65 25 x 21,65
[ - ] 4 4 4 3 3 4
[ - ] (2)
[ mm ] 1.8 1.8 1.8 1.8 1.8 1.8
[ - ] 1.00 1.00 0.92 1.00 0.99 0.97
(3)
1 1 1 2 2 2
[ A ] 1,89 1,89 2,11 3,04 3,07 3,41
[W] 1120 1130 1250 1810 1830 2030
[Pa] 30 30 30 30 30 30
[Pa] 380 380 340 425 425 355
G4 G4 G4 G4 G4 G4
[m2] 1.44 1.44 1.44 2.92 2.92 2.92
1 1 1 1 1 1
[kW] 6.4 6.4 6.4 9.6 9.6 9.6
2 2 2 3 3 3
[ - ] (4)
[ kW] 18.1 18.1 18.5 36.3 38.1 41.3
[m2] 0.65 0.65 0.65 1.05 1.05 1.05
[ kW] 15,5 15,8 16,3 28,4 29 29,8
[m2] 0.65 0.65 0.65 1.05 1.05 1.05
[m3/h] 2.552 2.696 2.98 3.250 3.768 4.948
[ kPa ] 15.6 18.2 25.3 40.0 39.6 42.4
[ kPa ] 14.72 15.13 15.55 7.69 8.42 10.13
[ dm3] 1.443 1.443 1.443 2.786 2.786 2.786
[ kg/h ] 11.86 11.62 9.66 28.79 27.49 17.85
[ kg/h ] 8 8 8 8 8 8
[ kW ] 6 6 6 6 6 6
[mm] 1998 1998 1998 1998 1998 1998
[mm] 1000 1000 1000 1750 1750 1750
[mm] 795 795 795 795 795 795
[dB(A)]
[kg] 375 385 393 570 585 595
TECHNICAL DATA
Unit power supply
Air Flow
DHZ - T water 15°C / 30°C
Cooling Capacity
Power consumption
DHW - T water 40°C / 45°C (30% e.g.)
Cooling Capacity
Power consumption
Compressor
Type
Power supply
Nominal Current
FLA
LRA
POE Oil charge
Finned coil evaporator
Front Surface
Geometry
Rows
Type of ns
Fin piDHCh
SHR
Indoor fan
Type
Number of fans
Fans absorbed current
Fans absorbed power
AESP
AESP (maximum speed)
Air Filter
Filtration
Overall surface
Fire resistance class
Electrical heaters
Total Heating Capacity
N° of heaters
Material
Hot gas Reheating Coil
Heating capacity
Front Surface
Hot Water reheating coil
Heat. capacity@45/40°water T
Front Surface
Water ow
Water side pressure drop
Water valve pressure drop
Internal volume
Humidier
Max theoretical capacity
Effective capacity
Absorbed power
Frame
H
L
D
Sound pressure level**
Weight
(*) At 1,5 meters height, 2 meters frontal distance in free eld; downow units [20 Pa AESP]
(1) : Scroll
(2) : Hydrolic
(3) : Radial EC
(4) : Aluminium
Tab.8 - Technical Data for water Cooled DX Units - DHW/ZDC/DHW/ZUC
