ELECTRICAL DATA 7.5 TON
7.5 TON STANDARD EFFICIENCY (R-410A) KGA092S4
1
Voltage - 60hz 208/230V - 3 Ph 460V - 3 Ph 575V - 3 Ph
Compressor 1 Rated Load Amps 13.1 6.1 4.4
Locked Rotor Amps 83.1 41 33
Compressor 2 Rated Load Amps 13.1 6.1 4.4
Locked Rotor Amps 83.1 41 33
Outdoor Fan
Motors (2)
Full Load Amps 2.4 1.3 1
(total) (4.8) (2.6) (2)
Power Exhaust
(1) 0.33 HP
Full Load Amps 2.4 1.3 1
Service Outlet 115V GFI (amps) 15 15 15
Indoor Blower
Motor
Horsepower 2 2 2
Full Load Amps 7.5 3.4 2.7
2
Maximum
Overcurrent
Protection
Unit Only 50 25 15
With (1) 0.33 HP
Power Exhaust
50 25 20
3
Minimum
Circuit
Ampacity
Unit Only 42 20 15
With (1) 0.33 HP
Power Exhaust
45 22 16
1
Extremes of operating range are plus and minus 10% of line voltage.
2
HACR type breaker or fuse.
3
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
8.5 TON STANDARD EFFICIENCY (R-410A) KGA102S4
1
Voltage - 60hz 208/230V - 3 Ph 460V - 3 Ph 575V - 3 Ph
Compressor 1 Rated Load Amps 14.5
6.3 6
Locked Rotor Amps 98
55 41
Compressor 2 Rated Load Amps 14.5
6.3 6
Locked Rotor Amps 98
55 41
Outdoor Fan
Motors (2)
Full Load Amps 2.4
1.3 1
(total) (4.8)
(2.6) (2)
Power Exhaust
(1) 0.33 HP
Full Load Amps 2.4
1.3 1
Service Outlet 115V GFI (amps) 15
15 15
Indoor Blower
Motor
Horsepower 2
2 2
Full Load Amps 7.5
3.4 2.7
2
Maximum
Overcurrent
Protection
Unit Only 50
25 20
With (1) 0.33 HP
Power Exhaust
60
25 25
3
Minimum
Circuit
Ampacity
Unit Only 45
21 19
With (1) 0.33 HP
Power Exhaust
48
22 20
1
Extremes of operating range are plus and minus 10% of line voltage.
2
HACR type breaker or fuse.
3
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
