Page 11
FACTORY INSTALLED OPTIONS/FIELD INSTALLED ACCESSORY AIR RESISTANCE - in. w.g.
Air Volume
cfm
Wet Indoor Coil
Electric Heat Economizer
Filters
Horizontal Roof
Curb
180S 240S MERV 8 MERV 13
4000 .02 .04 - - - - - - .04 .06 .06
4250 .02 .04 - - - - - - .04 .06 .07
4500 .02 .05 - - - - - - .04 .07 .07
4750 .02 .05 - - - - - - .04 .07 .08
5000 .03 .05 - - - - - - .05 .07 .08
5250 .03 .06 - - - - - - .05 .07 .09
5500 .03 .07 - - - - - - .05 .07 .10
5750 .03 .07 - - - - - - .05 .08 .11
6000 .04 .08 .01 - - - .05 .08 .11
6250 .04 .08 .01 .01 .05 .08 .12
6500 .04 .09 .01 .02 .05 .08 .13
6750 .05 .10 .01 .03 .05 .08 .14
7000 .05 .10 .01 .04 .06 .08 .15
7250 .06 .11 .01 .05 .06 .09 .16
7500 .06 .12 .01 .06 .06 .09 .17
8000 .07 .13 .02 .09 .06 .09 .19
8500 .08 .15 .02 .11 .06 .09 .21
9000 .09 .16 .04 .14 .07 .10 .24
9500 .10 .18 .05 .16 .07 .10 .26
10,000 .11 .20 .06 .19 .07 .11 .29
10,500 .12 .22 .09 .22 .07 .11 .31
11,000 .14 .24 .11 .25 .08 .11 .34
BLOWER DATA
