Page 2
506393−01 11/2010
KHA180 & 240 Dimensions
BOTTOM POWER ENTRY
127 X 203 mm (5 X 8 in.)
BOTTOM SUPPL
Y
AIR OPENINGS
BOTTOM RETURN
AIR OPENING
4−1/4
(108)
28
4 (102)
102
(4)
12−3/8
(314)
20 (508)
15 (381)
60−1/2 (1537)
AA BB
CC
DD
CENTER OF
GRAVITY
EE
FF
TOP VIEW
(711)
28
(711)
12−3/8
(314)
3−1/4
(83)
54−1/4
(1378)
51
(1295)
90−1/8
(2289)
29−1/4
(743)
91−1/8 (2315)
BASE
CONDENSA
TE
DRAIN
5−3/8
(137)
SIDE
ELECTRICAL
INLETS
END VIEW SIDE VIEW
129−1/2 (3289)
BASE
128−1/2
(3264)
LIFTING HOLES
(For Rigging
Front and Back)
1/2
(13)
FORKLIFT SLOTS
(Front and Left Sides Only)
(11
4)
4−1/2
20 (508)
ALTERNATE (THRU THE BASE)
CONDENSA
TE DRAIN LOCATION
1−5/8 in. (41 mm) Diameter
18 (457)
28−3/8
(721)
5−5/8 (143)
91−1/8 (2315)
BASE
129−1/2 (3289)
BASE
54−1/4
(1378)
