LGT/LCT036, 048, 060, 072
LGT048
Unit Voltage 208/230V - 1 Ph 208/230V - 3 Ph 460V - 3Ph 575V - 3Ph
Power Exhaust Option W / P.E. W / O P.E. W / P.E. W / O P.E. W / P.E. W / O P.E. W / P.E. W / O P.E.
Diagram
Key
Class
Blower
Type
Amps
F10
2
CC LS 8A 8A 8A 8A 8A 8A 8A 8A
F27 CC LS - - - - - - 7.5A 7.5A
F30 CC LS 10A 10A 10A 10A 5A 5A - -
F31 CC LS - 15A - 15A 15A - -
F57 CC LS - - - - 3.5A 3.5A 5A 5A
F57 CC HS - - - - 10A 10A 7.5A 7.5A
F61
2
J LS 50A 45A 35A 35A 15A 15A 15A 15A
F61
2
J HS - - 35A 30A 15A 15A 15A 15A
CB10
3
- LS 50A 45A 35A 35A 15A 15A 15A 15A
CB10
3
- HS - - 35A 30A 15A 15A 15A 15A
2
Fuses F10 and F61 are only used on units with SCCR installed.
3
Units using Circuit Breakers will use CB10 option.
LGT060
Unit Voltage 208/230V - 1 Ph 208/230V - 3 Ph 460V - 3Ph 575V - 3Ph
Power Exhaust Option W / P.E. W / O P.E. W / P.E. W / O P.E. W / P.E. W / O P.E. W / P.E. W / O P.E.
Diagram
Key
Class
Blower
Type
Amps
F10
2
CC LS 8A 8A 8A 8A 8A 8A 8A 8A
F27 CC LS - - - - - - 7.5A 7.5A
F30 CC LS 10A 10A 10A 10A 5A 5A - -
F31 CC LS - 15A - 15A 15A - -
F57 CC LS - - - - 3.5A 3.5A 5A 5A
F57 CC HS - - - - 10A 10A 7.5A 7.5A
F61
2
J LS 60A 60A 40A 40A 15A 15A 15A 15A
F61
2
J HS - - 40A 35A 20A 15A 15A 15A
CB10
3
- LS 60A 60A 40A 40A 15A 15A 15A 15A
CB10
3
- HS - - 40A 35A 20A 15A 15A 15A
2
Fuses F10 and F61 are only used on units with SCCR installed.
3
Units using Circuit Breakers will use CB10 option.
