Lennox LGH Series Installation Instructions

Page 48
LGH/LCH036, 048, 060, 072, 074
TABLE 11
LGH/LCH036S/H REHEAT NORMAL OPERATING PRESSURES - ALL-ALUMINUM COIL
Outdoor Coil Entering Air Temperature
65 °F 75 °F 85 °F 95 °F 105 °F 115 °F
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
113 236 116 273 117 316 119 362 119 415 121 480
121 240 124 276 126 318 129 363 130 414 132 475
138 251 142 288 144 330 147 375 150 425 153 482
153 268 159 301 164 342 168 388 171 439 175 496
TABLE 12
LGH/LCH048S/H NORMAL OPERATING PRESSURES - ALL-ALUMINUM COIL
Outdoor Coil Entering Air Temperature
65 °F 75 °F 85 °F 95 °F 105 °F 115 °F
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
114 244 117 282 116 329 116 383 118 457 119 551
123 249 125 288 125 332 125 382 127 446 134 486
139 259 142 298 146 341 148 388 148 447 155 499
155 274 161 313 164 357 168 404 171 457 176 511
TABLE 13
LGH/LCH048S/H REHEAT NORMAL OPERATING PRESSURES - ALL-ALUMINUM COIL
Outdoor Coil Entering Air Temperature
65 °F 75 °F 85 °F 95 °F 105 °F 115 °F
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
112 250 115 288 118 331 120 380 119 445 121 533
122 254 124 292 127 333 126 391 129 447 130 551
139 264 143 302 146 344 149 392 151 444 154 502
157 280 161 318 166 360 170 406 173 457 176 512
TABLE 14
LGH/LCH060S/H NORMAL OPERATING PRESSURES - ALL-ALUMINUM COIL
Outdoor Coil Entering Air Temperature
65 °F 75 °F 85 °F 95 °F 105 °F 115 °F
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
111 238 114 274 115 316 117 364 119 420 121 488
128 233 122 278 124 320 126 367 128 422 130 486
137 253 141 292 144 329 146 375 148 427 150 486
154 267 160 300 163 344 167 389 170 438 173 494
TABLE 15
LGH/LCH060S/H REHEAT NORMAL OPERATING PRESSURES - ALL-ALUMINUM COIL
Outdoor Coil Entering Air Temperature
65 °F 75 °F 85 °F 95 °F 105 °F 115 °F
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
112 248 114 285 115 327 117 378 119 436 122 500
121 253 124 289 125 331 127 378 129 432 131 496
139 264 142 301 145 342 147 390 149 445 151 508
158 280 162 315 166 356 170 402 173 452 177 509
