Page 49
LGH/LCH036, 048, 060, 072, 074
TABLE 16
LGH/LCH072H NORMAL OPERATING PRESSURES - ALL-ALUMINUM COIL
Outdoor Coil Entering Air Temperature
65 °F 75 °F 85 °F 95 °F 105 °F 115 °F
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
113 261 115 300 116 347 118 402 119 492 123 512
122 266 124 307 126 349 126 402 128 467 132 518
140 277 143 316 145 360 147 411 149 472 151 540
159 291 161 329 164 375 168 423 172 478 174 537
TABLE 17
LGH/LCH072H REHEAT NORMAL OPERATING PRESSURES - ALL-ALUMINUM COIL
Outdoor Coil Entering Air Temperature
65 °F 75 °F 85 °F 95 °F 105 °F 115 °F
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
109 260 111 300 112 348 114 403 118 459 119 524
122 270 120 304 121 351 124 405 126 463 128 526
135 279 139 318 142 362 144 408 145 470 148 540
154 299 158 336 162 378 165 425 169 476 172 533
TABLE 18
LGH/LCH074H NORMAL OPERATING PRESSURES - ALL-ALUMINUM COIL
Outdoor Coil Entering Air Temperature
65 °F 75 °F 85 °F 95 °F 105 °F 115 °F
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
112 257 113 298 114 348 116 403 118 476 121 602
120 261 122 301 123 347 124 403 127 466 129 556
136 271 140 310 143 354 145 401 145 460 147 525
154 290 157 327 161 370 165 416 168 468 171 526
TABLE 19
LGH/LCH074H REHEAT NORMAL OPERATING PRESSURES - ALL-ALUMINUM COIL
Outdoor Coil Entering Air Temperature
65 °F 75 °F 85 °F 95 °F 105 °F 115 °F
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
113 261 113 301 116 349 117 403 119 463 121 521
121 266 123 305 124 351 126 404 128 460 130 538
139 248 143 285 146 326 148 372 148 467 151 532
158 300 161 336 165 379 170 428 173 478 175 537
