Page 18
BLOWER DATA - DIRECT DRIVE - 094U, 122U, 152U
BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY (NO HEAT SECTION) WITH DRY INDOOR COIL AND AIR
FILTERS IN PLACE.
FOR ALL UNITS ADD:
1 − Wet indoor coil air resistance of selected unit.
2 − Any factory installed options air resistance (heat section, economizer, etc.)
3 − Any eld installed accessories air resistance (duct resistance, diffuser, etc.)
See page 21 for wet coil and option/accessory air resistance data.
MAXIMUM STATIC PRESSURE WITH GAS HEAT - 2.0 in. w.g.
Total
Air Volume
cfm
Total Static Pressure - in. w.g.
0.2 0.4 0.6 0.8 1.0 1.2 1.4
RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts
1750 711 188 771 279 836 366 905 453 975 544 1044 640 1109 737
2000 752 242 812 332 876 420 944 510 1011 606 1075 709 1138 812
2250 799 300 860 389 923 479 988 575 1052 678 1113 787 1171 896
2500 853 362 914 453 976 548 1038 650 1097 761 1154 877 1209 990
2750 914 434 974 529 1033 629 1091 739 1146 858 1199 979 1250 1098
3000 980 513 1037 614 1092 720 1146 837 1198 961 1247 1088 1295 1215
3250 1048 598 1101 705 1153 819 1203 941 1251 1071 1298 1206 1343 1343
3500 1116 693 1166 809 1214 931 1261 1060 1307 1198 1351 1341 1395 1489
3750 1185 806 1232 931 1277 1063 1322 1201 1365 1348 1407 1499 1448 1657
4000 1254 937 1299 1072 1341 1214 1383 1363 1424 1518 1464 1679 1503 1844
4250 1324 1089 1366 1234 1406 1386 1445 1545 1484 1708 1522 1876 1559 2046
4500 1395 1262 1433 1417 1471 1579 1508 1745 1544 1913 1581 2084 1616 2256
4750 1465 1455 1501 1619 1536 1787 1571 1957 1606 2128 1641 2299 1675 2470
5000 1534 1666 1568 1834 1602 2004 1635 2174 1668 2345 1701 2514 1735 2682
5250 1603 1887 1635 2055 1667 2224 1699 2392 1731 2559 1763 2724 - - - - - -
5500 1671 2110 1702 2275 1733 2441 1764 2605 - - - - - - - - - - - - - - - - - -
5750 1738 2325 1768 2488 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Total
Air Volume
cfm
Total Static Pressure - in. w.g.
1.6 1.8 2.0 2.2 2.4 2.6
RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts
1750 1172 833 1231 932 1287 1039 1340 1156 1391 1283 1442 1426
2000 1197 913 1253 1019 1306 1135 1357 1261 1407 1398 1457 1547
2250 1227 1003 1280 1117 1330 1242 1379 1378 1428 1525 1477 1680
2500 1261 1103 1311 1226 1360 1361 1407 1507 1454 1663 1501 1826
2750 1299 1219 1347 1350 1394 1494 1440 1649 1485 1813 1530 1982
3000 1342 1346 1388 1487 1432 1640 1476 1803 1520 1973 1563 2146
3250 1388 1485 1432
1638 1475 1800 1517 1969 1558 2143 1600 2319
3500 1437 1643 1479 1805 1519 1975 1560 2148 1600 2325 1640 2502
3750 1489 1821 1528 1990 1567 2164 1605 2340 1645 2517 1685 2693
4000 1541 2014 1579 2187 1616 2364 1654 2540 1693 2715 1732 2887
4250 1596 2218 1632 2393 1668 2569 1705 2742 1743 2913 - - - - - -
4500 1652 2429 1687 2603 1722 2775 1759 2944 - - - - - - - - - - - -
4750 1709 2641 1743 281
1 1778 2979 - - - - - - - - - - - - - - - - - -
5000 1768 2850 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
5250 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
5500 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
5750 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
