ELECTRICAL DATA 7.5 TON
BELT DRIVE LGH094U4M
1
Voltage - 60hz 208/230V - 3 Ph 460V - 3 Ph 575V - 3 Ph
Compressor 1 Rated Load Amps 13.1 6.1 4.4
Locked Rotor Amps 83.1 41 33
Compressor 2 Rated Load Amps 13.1 6.1 4.4
Locked Rotor Amps 83.1 41 33
Outdoor Fan
Motors (3)
Full Load Amps 2.8 1.4 1.1
(total) (8.4) (4.2) (3.3)
Power Exhaust
(1) 0.33 HP
Full Load Amps 2.4 1.3 1
Service Outlet 115V GFI (amps) 15 15 20
Indoor Blower
Motor
Horsepower 2 3 5 2 3 5 2 3 5
Full Load Amps 7.5 10.6 16.7 3.4 4.8 7.6 2.7 3.9 6.1
2
Maximum
Overcurrent
Protection
Unit Only 60 60 70 25 30 35 20 20 25
With (1) 0.33 HP
Power Exhaust
60 60 70 30 30 35 20 20 25
3
Minimum
Circuit
Ampacity
Unit Only 50 53 60 24 25 28 18 19 22
With (1) 0.33 HP
Power Exhaust
52 55 62 25 27 30 19 20 23
NOTE - All units have a minimum Short Circuit Current Rating (SCCR) of 5000 amps.
1
Extremes of operating range are plus and minus 10% of line voltage.
2
HACR type breaker or fuse.
3
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
4
Factory installed circuit breaker not available.
ELECTRICAL DATA 10 TON
BELT DRIVE LGH122U4M
1
Voltage - 60hz 208/230V - 3 Ph 460V - 3 Ph 575V - 3 Ph
Compressor 1 Rated Load Amps 16.5 7.2 5.5
Locked Rotor Amps 110 52 38.9
Compressor 2 Rated Load Amps 16 7.8 5.7
Locked Rotor Amps 110 52 38.9
Outdoor Fan
Motors (3)
Full Load Amps 2.8 1.4 1.1
(total) (8.4) (4.2) (3.3)
Power Exhaust
(1) 0.33 HP
Full Load Amps 2.4 1.3 1
Service Outlet 115V GFI (amps) 15 15 20
Indoor Blower
Motor
Horsepower 2 3 5 2 3 5 2 3 5
Full Load Amps 7.5 10.6 16.7 3.4 4.8 7.6 2.7 3.9 6.1
2
Maximum
Overcurrent
Protection
Unit Only 70 70 80 30 35 35 25 25 25
With (1) 0.33 HP
Power Exhaust
70 70 80 35 35 35 25 25 30
3
Minimum
Circuit
Ampacity
Unit Only 57 60 66 27 29 31 21 22 24
With (1) 0.33 HP
Power Exhaust
59 62 69 28 30 33 22 23 25
NOTE - All units have a minimum Short Circuit Current Rating (SCCR) of 5000 amps.
1
Extremes of operating range are plus and minus 10% of line voltage.
2
HACR type breaker or fuse.
3
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
4
Factory installed circuit breaker not available.
5
Disconnect must be eld furnished.
