TABLE 7 580445-03
LGH/LCH092H Normal Operating Pressures - All-Aluminum - TXV
Outdoor Coil Entering Air Temperature
65 °F 75 °F 85 °F 95 °F 105 °F 115 °F
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Circuit 1 110 238 112 275 114 317 116 364 118 415 121 473
119 240 121 277 123 319 125 365 127 417 130 474
139 244 142 283 143 324 145 371 148 422 149 477
158 255 162 292 167 334 171 378 173 428 174 482
Circuit 2 116 227 118 265 119 307 121 356 123 409 126 474
125 230 127 267 128 310 130 357 132 410 135 473
143 230 147 272 148 314 150 361 152 413 154 473
161 242 167 280 171 322 174 368 176 419 178 474
TABLE 8 580446-03
LGH/LCH102H Normal Operating Pressures - All-Aluminum - TXV
Outdoor Coil Entering Air Temperature
65 °F 75 °F 85 °F 95 °F 105 °F 115 °F
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Circuit 1 110 232 112 270 113 313 116 360 118 411 121 468
120 235 121 274 123 316 125 363 127 415 132 469
139 243 142 281 145 323 146 371 148 423 151 479
155 254 160 288 164 331 168 377 171 427 175 483
Circuit 2 111 235 112 276 114 324 116 381 118 457 122 548
120 237 121 277 123 324 125 379 127 449 131 532
140 243 141 281 142 326 144 378 147 440 150 512
159 254 163 287 165 330 167 379 169 436 172 500
TABLE 9 580447-02
LGH/LCH120H Normal Operating Pressures - All-Aluminum - TXV
Outdoor Coil Entering Air Temperature
65 °F 75 °F 85 °F 95 °F 105 °F 115 °F
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Circuit 1
113 251 113 290 112 331 116 383 117 439 120 520
120 254 123 293 124 338 126 388 127 441 129 510
139 264 142 303 144 345 147 393 146 445 148 510
155 278 160 314 164 357 167 403 169 456 173 512
Circuit 2
110 251 111 287 111 329 114 388 117 454 120 538
119 249 120 291 122 336 124 389 126 447 128 520
139 259 142 297 143 337 145 390 144 444 149 514
155 274 160 307 164 349 166 393 169 448 170 510
