LHT078-150 PARTS ARRANGEMENT
FIGURE 1
UNIT
CONTROLLER
INDOOR
COIL
OUTDOOR FANS
(3 ON 122 & 150)
OUTDOOR
COIL
COMPRESSORS
CONDENSATE
DRAIN
FILTERS
(FOUR - 20 X 25 X 2”)
ECONOMIZER
(OPTIONAL)
BLOWER
(DIRECT DRIVE)
ELECTRIC HEAT
(OPTIONAL)
WIRELESS
BOARD
WIFI
ANTENNA
REVERSING
VALVE
LHT078-150 CONTROL BOX
FIGURE 2
W4
A55
K65
T3
T1
T18
TB13
K1
K2
S117
SHADED AREA IS A HINGED PANEL IN FRONT OF
CONTROLS AREA (OPTIONAL A173 LOCATION)
