C1DAMP20B-1 MOTORIZED OUTDOOR AIR DAMPER
FIGURE 18
LOWER PANEL
COVER PANEL
MOTORIZED
DAMPER
HORIZONTAL
RETURN AIR
OPENING
HORIZONTAL
SUPPLY AIR
OPENING
COMPRESSOR
SECTION
LOWER PANEL
C1DAMP10B-1 MANUAL OUTDOOR AIR DAMPER
COVER PANEL
HORIZONTAL
RETURN AIR
OPENING
HORIZONTAL
SUPPLY AIR
OPENING
COMPRESSOR
SECTION
MANUAL DAMPER
