Technical Information
Service Manual
Model
LI024CI-170P432-1
LI024CO-170P432-1
LI024HI-170P432-1
LI024HO-170P432-1
Power Supply
Rated Voltage V~ 208/230 208/230
Rated Frequency Hz 60 60
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity(Min~Max) Btu/h 22000 22000
Heating Capacity(Min~Max) Btu/h / 24000
Cooling Power Input(Min~Max) W 2010 1950
Heating Power Input(Min~Max) W / 2070
Cooling Power Current A 8.50 8.50
Heating Power Current A / 8.50
Rated Input W 2500 2900
Rated Current A 11.00 11.00
Air Flow Volume(SH/H/M/L) CFM 677/588/471/412 677/588/471/412
Dehumidifying Volume Pint/h 2 2
EER (Btu/h)/W 10.95 11.25
COP (Btu/h)/W / 11.75
SEER 19.00 19.00
HSPF / 10
Application Area yd
2
27.50-40.66 27.50-40.66
Indoor Unit
Model of indoor unit LI024CI-170P432-1 LI024HI-170P432-1
Indoor Unit Product Code 20Y07 20Y17
Fan Type Cross-ow Cross-ow
Diameter Length(DXL) inch Φ4 1/4X32 43/64 Φ4 1/4X32 43/64
Fan Motor Cooling Speed(SH/H/M/L) r/min 1300/1150/1000/850 1300/1150/1000/850
Fan Motor Heating Speed(SH/H/M/L) r/min / 1300/1150/1000/850
Output of Fan Motor W 30 30
Fan Motor RLA A 0.55 0.55
Fan Motor Capacitor μF 3 3
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter inch Φ17/64 Φ17/64
Row-n Gap inch 2-1/16 2-1/16
Coil Length (LXDXW) inch 33 1/4×1×13 1/2 33 1/4×1×13 1/2
Swing Motor Model MP35CJ MP35CJ
Output of Swing Motor W 2.5 2.5
Fuse A 3.15 3.15
Sound Pressure Level(SH/H//M/L) dB (A) 49/45/41/37 49/45/41/37
Sound Power Level(SH/H//M/L) dB (A) 59/55/51/47 59/55/51/47
Dimension (WXHXD) inch 42 7/16X12 13/16X9 11/16 42 7/16X12 13/16X9 11/16
Dimension of Carton Box (LXWXH) inch 45X16 1/8X13 3/16 45X16 1/8X13 3/16
Dimension of Package (LXWXH) inch 45 3/16X16 1/4X13 3/4 45 3/16X16 1/4X13 3/4
Net Weight Ib 37.5 37.5
Gross Weight Ib 45.2 45.2
