3
Technical Information
Service Manual
2. Specications
2.1 Specication Sheet
Model
LI012CI-170P432-1
LI012CO-170P432-1
LI012HI-170P432-1
LI012HO-170P432-1
Power Supply
Rated Voltage V~ 208/230 208/230
Rated Frequency Hz 60 60
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity Btu/h 12000 12000
Heating Capacity Btu/h / 13000
Cooling Power Input W 1256 1297
Heating Power Input W / 1172
Cooling Power Current A 5.5 5.6
Heating Power Current A / 5.1
Rated Input W 1450 1500
Rated Current A 6.3 6.5
Air Flow Volume(SH/H/M/L) CFM 371/294/235/182 371/294/235/182
Dehumidifying Volume Pint/h 1.4 1.4
EER (Btu/h)/W 9.55 9.25
COP (Btu/h)/W / 11.09
SEER 17 17
HSPF / 9
Application Area yd
2
19.14-28.7 19.14-28.7
Indoor Unit
Model of indoor unit LI012CI-170P432-1 LI012HI-170P432-1
Indoor Unit Product Code 20Y03 20Y11
Fan Type Cross-ow Cross-ow
Diameter Length(DXL) inch Φ3 55/64X25 Φ3 55/64X25
Fan Motor Cooling Speed (SH/H/M/L/SL) r/min 1350/1200/1000/800/- 1350/1200/1000/800/-
Fan Motor Heating Speed (SH/H/M/L/SL) r/min / 1350/1200/1000/900/-
Output of Fan Motor W 20 20
Fan Motor RLA A 0.31 0.31
Fan Motor Capacitor μF 1.5 1.5
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter inch Φ3/16 Φ3/16
Row-n Gap inch 2-1/16 2-1/16
Coil Length (LXDXW) inch 25X57/64X12 3/64 25X57/64X12 3/64
Swing Motor Model MP24BA MP24BA
Output of Swing Motor W 1.5 1.5
Fuse A 3.15 3.15
Sound Pressure Level(SH/H/M/L/SL) dB (A) 42/39/34/28/-
Cooling:42/39/34/28/-
Heating:43/39/34/30/-
Sound Power Level (SH/H/M/L/SL) dB (A) 52/49/44/38/-
Cooling:52/49/44/38/-
Heating:53/49/44/40/-
Dimension (WXHXD) inch 33 1/4X11 3/8X8 1/4 33 1/4X11 3/8X8 1/4
Dimension of Carton Box (LXWXH) inch 36 1/8X11X14 5/16 36 1/8X11X14 5/16
Dimension of Package (LXWXH) inch 36 1/4X11X15 36 1/4X11X15
Net Weight Ib 22.1 22.1
Gross Weight Ib 26.5 26.5
To Next Page
