12
Technical Information
Service Manual
3. Outline Dimension Diagram
3.1 Indoor Unit
W
D
H
Φ2 3/16
Φ2 3/16
4 11/16 21 5/16 7 1/4
3 5/16
5
1 3/8
1 3/8
427 7 3/16
5 1/2
7 1/2
1 1/2
Φ2 3/16
Φ2 3/16
3 1/8
6
1 11/16
8 1/8 27 7 5/16
Φ2 3/4
Φ2 3/4
MODEL W H D
12K 33 1/4 11 3/8 8 1/4
18K 38 3/16 11 13/16 8 13/16
24K 42 7/16 12 13/16 9 11/16
Unit:inch
QB LI012CI-170P432-1
LI012HI-170P432-1
LI024CI-170P432-1
LI024HI-170P432-1
LI018CI-170P432-1
LI018HI-170P432-1
