Lennox LI024CI-170P432-1 User Manual

4
Technical Information
Service Manual
The above data is subject to change without notice; please refer to the nameplate of the unit.
Outdoor Unit
Model of Outdoor Unit LI012CO-170P432-1 LI012HO-170P432-1
Outdoor Unit Product Code 20Y04 20Y12
Compressor Manufacturer/Trademark
ZHUHAI LANDA COMPRESSOR
CO., LTD
ZHUHAI LANDA COMPRESSOR
CO., LTD
Compressor Model QXF-A102zE190B QXF-A102zE190B
Compressor Oil FW68DA FW68DA
Compressor Type Rotary Rotary
Compressor L.R.A. A / /
Compressor RLA 6.6 6.6
Compressor Power Input W 1023 1023
Overload Protector HPC115/95U1/KSD115ºC HPC115/95U1/KSD115ºC
Throttling Method Capillary Capillary
Operation temp ºF 61~86 61~86
Ambient temp (cooling) ºF 0~115 0~115
Ambient temp (heating) ºF / -4~75
Condenser Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter inch Φ1/16 Φ5/16
Rows-n Gap inch 1-1/16 1-1/16
Coil Length (LXDXW) inch 28 5/16X1/2X19 1/2 36 21/32X3/4X21 21/32
Fan Motor Speed rpm 900 900
Output of Fan Motor W 30 30
Fan Motor RLA A 0.37 0.37
Fan Motor Capacitor μF 2.5 2.5
Air Flow Volume of Outdoor Unit CFM 942 942
Fan Type Axial-ow Axial-ow
Fan Diameter inch Φ15 33/64 Φ15 33/64
Defrosting Method / Automatic Defrosting
Climate Type T1 T1
Isolation I I
Moisture Protection IPX4 IPX4
Design Pressure(High) PSIG 550 550
Design Pressure(Low) PSIG 240 240
Sound Pressure Level (H/M/L) dB (A) 50/-/- 50/-/-
Sound Power Level (H/M/L) dB (A) 60/-/- 60/-/-
Dimension (WXHXD) inch 30 9/16X21 1/4X12 5/8 30 9/16X21 1/4X12 5/8
Dimension of Carton Box (LXWXH) inch 32 9/32X13 63/64X22 27/32 32 9/32X13 63/64X22 27/32
Dimension of Package (LXWXH) inch 32 13/32X14 3/32X23 27/64 32 13/32X14 3/32X23 27/64
Net Weight Ib 60.6 62.8
Gross Weight Ib 66.2 68.4
Refrigerant R410A R410A
Refrigerant Charge oz 25.0 28.2
Connection
Pipe
Length ft 24.6 24.6
Gas Additional Charge oz/ft 0.2 0.2
Outer Diameter Liquid Pipe inch 1/4 1/4
Outer Diameter Gas Pipe inch 3/8 3/8
Max Distance Height ft 32.8 32.8
Max Distance Length ft 65.6 65.6
Note:The connection pipe applies metric diameter.
