77
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
Qty
LI012CI-170P432-1 LI012HI-170P432-1
Product Code 20Y03 20Y11
1 Front Panel 27230014341 27230014341 1
2 Filter Sub-Assy 1112246803 1112246803 2
3 Display Board 30565260 30565260 1
4 Front Case Assy 00000200045 00000200045 1
5 Guide Louver 1051293101 1051293101 1
6 Helicoid Tongue 26112436 26112436 1
7 Left Axile Bush 10512037 10512037 1
8 Rear Case assy 00000100093 00000100093 1
9 Drainage Hose 05230014 05230014 1
10 Ring of Bearing 26152022 26152022 1
11 O-Gasket sub-assy of Bearing 76512051 76512051 1
12 Evaporator Supper 24212179 24212179 1
13 Cold Plasma Generator / / /
14 Evaporator Assy 011001060162 011001060162 1
15 Wall Mounting Frame 01252484 01252484 1
16 Cross Flow Fan 10352056 10352056 1
17 Fan Motor 1501214607 1501214607 1
18 Connecting pipe clamp 2611216401 2611216401 1
19 Rubber Plug (Water Tray) 76712012 76712012 1
20 Stepping Motor 1521210710 1521210710 1
21 Crank 73012005 73012005 1
22 Electric Box Assy 100002067858 100002067859 1
23 Axile Bush 10542036 10542036 1
24 Terminal Board 42011233 42011233 1
25 Jumper 4202021917 4202021917 1
26 Main Board 300002061161 300002061159 1
27 Screw Cover 2425203001 2425203001 1
28 Electric Box Cover Sub-Assy 01705306007501 01705306007501 1
29 Shield Cover of Electric Box Cover 01592150 01592150 1
30 Electric Box Cover 2011220701 2011220701 1
31 Power Cord / / /
32 Connecting Cable 4003038506 4003038506 1
33 Remote Controller 30510525_X34306 30510525_X34306 1
To Next Page
