2. Specications
2.1 Specication Sheet
Model LNINVE052/LNINVC052 LNINVE063/LNINVC063
Product Code CB162007700_K96357 CB162007800_K96357
Power
Supply
Rated Voltage V~ 220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity W 5200 6300
Heating Capacity W 5850 6300
Cooling Power Input W 1590 1930
Heating Power Input W 1790 1930
Cooling Power Current A 7.05 8.56
Heating Power Current A 7.94 8.56
Rated Input W 2650 2700
Rated Current A 11.76 11.98
Air Flow Volume(SH/H/M/L/SL) m
3
/h 850/780/650/550/- 950/800/700/550/-
Dehumidifying Volume L/h 1.8 2.5
EER W/W 3.27 3.26
COP W/W 3.27 3.26
SEER W/W / /
HSPF W/W / /
Application Area m
2
23-34 32-50
Indoor
Unit
Model of indoor unit LNINVE052 LNINVE063
Fan Type Cross-ow Cross-ow
Diameter Length(DXL) mm Φ98X710 Φ98X765
Fan Motor Cooling Speed (SH/H/M/L/SL) r/min 1260/1050/920/730/- 1260/1100/950/750/-
Fan Motor Heating Speed (SH/H/M/L/SL) r/min 1320/1200/1100/1000/- 1320/1200/1100/950/-
Output of Fan Motor W 20 35
Fan Motor RLA A 0.29 0.31
Fan Motor Capacitor μF 1.5 2.5
Input of Heater W / /
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7 Φ7
Row-n Gap mm 2-1.4 2-1.5
Coil Length (LXDXW) mm 715X25.4X304.8 765X25.4X342.9
Swing Motor Model MP28VB MP35XX
Output of Swing Motor W 2 2.5
Fuse A 3.15 3.15
Sound Pressure Level (H) dB (A) 44 45
Sound Power Level (H) dB (A) 54 55
Dimension (WXHXD) mm 940X298X200 1007X315X219
Dimension of Carton Box (LXWXH) mm 1010X285X380 1073X395X313
Dimension of Package (LXWXH) mm 1013X288X395 1076X398X328
Net Weight kg 13 16
Gross Weight kg 17 21
