94
Installation and Maintenance
Service Manual
Procedure
Steps
a
b
c
clasps
clasps
temperature sensor
electric box cover
earth wire screws
panel case
4.Remove electric box assy
Unscrew the screws xing earth wire.
Break out the clasps of electric box cover to
remove the electric box cover.
Pull out the temperature sensor.
To Next Page
