Electrical
ELECTRIC HEAT DATA — LRP14HP Only
Model No.LRP14HP24 LRP14HP30 LRP14HP36
208/230V 208/230V 208/230V
Compressor
Rated Load Amps 10.9 13.5 15.4
Locked Rotor Amps59.3 72.5 83.9
Outdoor Fan
Motor
Full Load Amps 1.0 1.0 1.0
Locked Rotor Amps1.9 1.9 1.9
Indoor
Blower Motor
Full Load Amps 2.8 2.8 4.1
Locked Rotor Amps3.9 3.9 4.4
1
Maximum
Overcurrent
Protection
Voltage 208V 240V 208V 240V 208V 240V
Unit only, no electric heat 25 25 30 30 35 35
5 kW 30 30 30 30 30 35
7.5 kW 40 45 40 45 40 45
10 kW 50 60 50 60 50 60
15 kW
Circuit 1 - - - - - - 50 60 50 60
Circuit 2- - - - - - 25 30 25 30
1
Maximum Overcurrent
Protection with Optional
Single-Point Power
Supply
5 kW 45 45 45 50 50 50
7.5 kW 60 60 60 60 60 70
10 kW 70 70 70 80 70 80
15 kW - - - - - - 90 100 100 110
2
Minimum
Circuit
Ampacity
Unit only, no electric heat 17.4 17.4 20.7 20.7 24.4 24.4
5 kW 25.4 28.8 25.4 28.8 26.7 30.1
7.5 kW 36.7 41.9 36.7 41.9 38 43.2
10 kW 47.9 54.9 47.9 54.9 49.2 56.2
3
Circuit 1 - - - - - - 47.9 54.9 49.2 56.2
Circuit 2- - - - - - 22.6 26 22.6 26
2
Minimum Circuit
Ampacity with Optional
Single-Point Power
Supply
5 kW 39.1 42.4 42.3 45.7 46 49.4
7.5 kW 50.3 55.6 53.6 58.8 57.2 62.5
10 kW 61.6 68.6 64.8 71.8 68.5 75.5
15 kW - - - - - - 87.4 97.8 91.1 101.5
NOTE - All units have a minimum Short Circuit Current Rating (SCCR) of 5000 amps.
NOTE - Extremes of operating range are plus and minus 10% of line voltage.
1
HACR type breaker or fuse.
2
3
A separate compressor circuit is required.
