Lennox MCFA Service Manual

77
Table 10. MPC048S4M
Number of Zones and Outdoor Unit Connection Sizes
NOTE - Letter = Indoor Unit Zone Connection on Outdoor Unit
Zone 1 (A) Zone 2 (B) Zone 3 (C) Zone 4 (D) Zone 5 (E)
1/4 in. liq + 1/2 in. gas 1/4 in. liq + 1/2 in. gas 1/4 in. liq + 3/8 in. gas 1/4 in. liq + 3/8 in. gas 1/4 in. liq + 3/8 in. gas
006 009 012 030 - - -
006 009 012 036 - - -
006 009 018 018 - - -
006 009 018 024 - - -
006 009 018 030 - - -
006 012 012 012 - - -
006 012 012 018 - - -
006 012 012 024 - - -
006 012 012 030 - - -
006 012 018 018 - - -
006 012 018 024 - - -
009 009 009 009 - - -
009 009 009 012 - - -
009 009 009 018 - - -
009 009 009 024 - - -
009 009 009 030 - - -
009 009 009 036 - - -
009 009 012 012 - - -
009 009 012 018 - - -
009 009 012 024 - - -
009 009 012 030 - - -
009 009 018 018 - - -
009 009 018 024 - - -
009 012 012 012 - - -
009 012 012 018 - - -
009 012 012 024 - - -
009 012 012 030 - - -
009 012 018 018 - - -
009 012 018 024 - - -
012 012 012 012 - - -
012 012 012 018 - - -
012 012 012 024 - - -
012 012 018 018 - - -
006 006 006 006 009
006 006 006 006 012
006 006 006 006 018
006 006 006 006 024
006 006 006 006 030
006 006 006 006 024
006 006 006 009 009
LEGEND:
CLEAR = No adapters required.
GRAY = 3/8 x 1/2 in. gas pipe adapter is required for line set connection to outdoor unit (furnished with outdoor unit).
BLACK = 1/4 x 3/8 in. liquid pipe adapter is required for line set connection to the 048 outdoor unit (furnished with outdoor unit).
1/2 x 5/8 in. gas pipe adapter is required for line set connection to the 048 outdoor unit (furnished with outdoor unit).
