Lennox Mini-Split Service Manual / Page 198

E0 Flowchart

Shut off the power supply and turn it on 1 min-

ute later. Is it still displaying the error code?

If the EEPROM chip is soldered on PCB, re-

place the PCB. Otherwise, check whether the

EEPROM chip is plugged in PCB properly?

Yes

Insert the EEPROM properly

Replace the indoor PCB.

Table of Contents3
