MULTI-ZONE SYSTEM COMBINATIONS
NOTE - For multi-zone systems, the total capacity of all indoor units must be 66% to 133% of the outdoor unit capacity.
Outdoor Unit
Model No.
Number
of
Zones
Indoor Unit
Capacity
Nominal Cooling Capacity at Rated
System Capacity (Btuh)
Nominal Heating Capacity at Rated
System Capacity (Btuh)
#1 #2 #3 #4 #5 #1 #2 #3 #4 #5 #1 #2 #3 #4 #5
MPA048S4M
2
009 024 - - - - - - - - - 8,854 23,432 - - - - - - - - - 9,294 24,601 - - - - - - - - -
012 018 - - - - - - - - - 11,790 17,461 - - - - - - - - - 12,650 18,655 - - - - - - - - -
012 024 - - - - - - - - - 11,691 23,322 - - - - - - - - - 11,961 24,402 - - - - - - - - -
018 018 - - - - - - - - - 16,826 16,826 - - - - - - - - - 18,245 18,245 - - - - - - - - -
018 024 - - - - - - - - - 16,748 23,631 - - - - - - - - - 18,155 25,210 - - - - - - - - -
024 024 - - - - - - - - - 23,294 23,294 - - - - - - - - - 24,855 24,855 - - - - - - - - -
3
009 009 009 - - - - - - 9,294 9,294 9,294 - - - - - - 9,680 9,680 9,680 - - - - - -
009 009 012 - - - - - - 9,063 9,063 11,906 - - - - - - 9,565 9,565 12,750 - - - - - -
009 009 018 - - - - - - 8,952 8,952 17,965 - - - - - - 9,540 9,540 18,455 - - - - - -
009 009 024 - - - - - - 8,834 8,834 23,332 - - - - - - 9,235 9,235 24,505 - - - - - -
009 012 012 - - - - - - 9,027 12,089 12,089 - - - - - - 9,425 12,850 12,850 - - - - - -
009 012 018 - - - - - - 9,001 11,636 17,334 - - - - - - 9,345 12,585 18,119 - - - - - -
009 012 024 - - - - - - 8,922 11,621 23,222 - - - - - - 9,330 11,950 24,395 - - - - - -
009 018 018 - - - - - - 8,844 17,193 17,193 - - - - - - 9,320 17,875 17,875 - - - - - -
009 018 024 - - - - - - 8,685 16,321 22,111 - - - - - - 9,220 16,675 22,660 - - - - - -
009 024 024 - - - - - - 8,421 21,121 21,121 - - - - - - 9,021 21,521 21,521 - - - - - -
012 012 012 - - - - - - 11,981 11,981 11,981 - - - - - - 12,648 12,648 12,648 - - - - - -
012 012 018 - - - - - - 11,945 11,945 17,021 - - - - - - 12,355 12,355 18,105 - - - - - -
012 018 018 - - - - - - 10,756 16,530 16,530 - - - - - - 11,550 18,035 18,035 - - - - - -
012 012 024 - - - - - - 11,583 11,583 23,111 - - - - - - 11,910 11,910 24,355 - - - - - -
012 018 024 - - - - - - 11,093 16,210 22,035 - - - - - - 11,755 16,545 22,580 - - - - - -
012 024 024 - - - - - - 9,900 20,768 20,768 - - - - - - 11,440 21,760 21,760 - - - - - -
018 018 018 - - - - - - 16,405 16,405 16,405 - - - - - - 17,170 17,170 17,170 - - - - - -
018 018 024 - - - - - - 15,383 15,383 20,270 - - - - - - 15,865 15,865 22,155 - - - - - -
1
One outdoor unit may be matched with one indoor unit for single zone applications. A second indoor unit can be added at a later date for multi-zone applications.
