Lennox MS8 SERIES

Page 92
MS8C / MS8H (208-230V)
3. Remove panel
* Remove the screws securing the coil guard to the
chassis.
* Remove coil guard.
COIL GUARD
4. Remove handle
* Remove the screws securing the handle to
chassis.
* Remove handle.
handle
HANDLE
5. Remove right-side panel.
* Remove screws securing the right-side panel to
the chassis, valve support and condenser.
* Remove right-side panel.
RIGHT-SIDE PLATE
