Page 97
Corp. 1244-L9
14. Remove Coil Support Plate.
* Remove screws securing the support plate to the
coil.
* Remove support plate.
COIL SUPPORT PLATE
15. Remove Chassis and Coil
Pull coil upwards to separate from the chassis.
COIL
CHASSIS
