Lennox Prodigy Installation & Setup Guide

Page 29
KEY COMPONENT KEY COMPONENT
A55 PANEL, MAIN K2,−1 CONTACTOR, COMPRESSOR 2
A59 PANEL, COMPRESSORS 3 AND 4 K3, −1 CONTACTOR, BLOWER
B1 COMPRESSOR 1 K10,−1,2 RELAY, OUTDOOR FAN 1
B2 COMPRESSOR 2 K14,−1 CONTACTOR, COMPRESSOR 3
B3 MOTOR, BLOWER K65−1,2 RELAY, EXHAUST FAN
B4 MOTOR, OUTDOOR FAN 1 K68,−1 RELAY, OUTDOOR FAN 2
B5 MOTOR, OUTDOOR FAN 2 K146,1 CONTACTOR, COMPRESSOR 4
B10 MOTOR, EXHAUST FAN 1 K149,−1 RELAY, OUTDOOR FAN 3
B11 MOTOR, EXHAUST FAN 2 K150,−1 RELAY, OUTDOOR FAN 4
B13 COMPRESSOR 3 K152,−1 RELAY, OUTDOOR FAN 5
B20 COMPRESSOR 4 K153,−1,2 RELAY, OUTDOOR FAN 6
B21 MOTOR, OUTDOOR FAN 3 L14 VALVE, SOLENOID REHEAT COIL 1
B22 MOTOR, OUTDOOR FAN 4 L30 VALVE, SOLENOID REHEAT COIL 2
B23 MOTOR, OUTDOOR FAN 5 P18 PLUG, EXHAUST FAN COMP
B24 MOTOR, OUTDOOR FAN 6 P24 PLUG, EXHAUST FAN
C1 CAPACITOR, OUTDOOR FAN 1 P47 PLUG, OUTDOOR FAN 1
C2 CAPACITOR, OUTDOOR FAN 2 P52 PLUG, OUTDOOR FAN 2
C6 CAPACITOR, EXHAUST FAN 1 P86 PLUG, OUTDOOR FAN INTERFACE
C8 CAPACITOR, EXHAUST FAN 2 P87 PLUG, OUTDOOR FAN INTERFACE 2
C18 CAPACITOR, OUTDOOR FAN 3 P106 PLUG, OUTDOOR FAN 3
C19 CAPACITOR, OUTDOOR FAN 4 P107 PLUG, OUTDOOR FAN 4
C20 CAPACITOR, OUTDOOR FAN 5 P108 PLUG, OUTDOOR FAN 5
C21 CAPACITOR, OUTDOOR FAN 6 P109 PLUG, OUTDOOR FAN 6
CB8 CIRCUIT, BREAKER T1 P118 PLUG, COMPRESSOR 3 AND 4, CONTROL
CB10 CIRCUIT BREAKER, MAIN DISCONNECT UNIT P119 PLUG, COMPRESSOR 3 AND 4, INPUT
CB18 CIRCUIT, BREAKER T18 P132 PLUG, EXHAUST FAN MOTOR 1
F6 FUSE, EXHAUST FAN P133 PLUG, EXHAUST FAN MOTOR 2
F10 FUSE, OUTDOOR FAN MOTOR P138 PLUG, EXHAUST FAN 2
F30 FUSE, TRANSFORMER T29 PRIMARY P263 PLUG, HIGH AND LOW PRESSURE SWITCHES
F31 FUSE, TRANSFORMER T29 SECONDARY P264 PLUG, BLOWER DECK
HR1 HEATER COMPRESSOR 1 P265 PLUG, CONTACTORS AND RELAYS
HR2 HEATER COMPRESSOR 2 P267 PLUG,OUTDOOR FAN AREA
HR5 HEATER COMPRESSOR 3 P268 PLUG, TRANSFORMERS
HR11 HEATER COMPRESSOR 4 P269 PLUG, HUMIDITROL
J11 JACK, GFI, RECEPTACLE P299 PLUG, SAFETY
J18 JACK, EXHAUST FAN COMP RT17 SENSOR, OUTDOOR AIR
J24 JACK, EXHAUST FAN S4 SWITCH, LIMIT HI PRESS COMPRESS 1
J47 JACK, OUTDOOR FAN 1 S7 SWITCH, LIMIT HI PRESS COMPRESS 2
J52 JACK, OUTDOOR FAN 2 S11 SWITCH, LOW PRESS, LOW AMBIENT KIT COMP 1
J86 JACK, OUTDOOR FAN INTERFACE S28 SWITCH, LIMIT HI PRESS COMPRESS 3
J87 JACK, OUTDOOR FAN INTERFACE 2 S42 SWITCH, OVERLOAD RELAY BLOWER MOTOR
J106 JACK, OUTDOOR FAN 3 S48 SWITCH, DISCONNECT
J107 JACK, OUTDOOR FAN 4 S49 SWITCH, FREEZE STAT COMPRESS 1
J108 JACK, OUTDOOR FAN 5 S50 SWITCH, FREEZE STAT COMPRESS 2
J109 JACK, OUTDOOR FAN 6 S53 SWITCH, FREEZE STAT COMPRESS 3
J118 JACK, COMPRESSOR 3 AND 4, CONTROL S84 SWITCH, LOW PRESS, LOW AMBIENT KIT COMP 2
J119 JACK, COMPRESSOR 3 AND 4, INPUT S85 SWITCH, LOW PRESS, LOW AMBIENT KIT COMP 3
J132 JACK, BLOWER , EXHAUST FAN MOTOR 1 S87 SWITCH, LOW PRESS, COMP 1
J133 JACK, BLOWER , EXHAUST FAN MOTOR 2 S88 SWITCH, LOW PRESS, COMP 2
J138 JACK, EXHAUST FAN 2 S94 SWITCH, LOW PRESS, LOW AMBIENT KIT COMP 4
J139 JACK, EXHAUST FAN 3 S95 SWITCH, FREEZE STAT COMPRESS 4
J263 JACK, HIGH AND LOW PRESSURE SWITCHES S96 SWITCH, LIMIT HI PRESS COMPRESS 4
J264 JACK, BLOWER DECK S97 SWITCH, LOW PRESS, COMP 4
J265 JACK, CONTACTORS AND RELAYS S98 SWITCH, LOW PRESS, COMP 3
