Page 3
Heat Exchanger
Combustion Air Inducer
Gas Valve
Air Intake Pipe
Control Box
(includes two-stage integrated control,
transformer and circuit breaker)
Blower Assembly
A
ccess Panel
Inner Access
Panel
FIGURE 1
