Parts Arrangement
Heat Exchanger
Gas Valve
Combustion
Air Inducer
Indoor Blower
Two-Stage Control
Cabinet
Panel
Inner Panel
Gas Pipe Inlet
(right side only)
Inlet Vent Pipe
Exhaust Vent Pipe
Exhaust Coupling
Intake Air Assembly
Rollout Switch
Burner Assembly
FIGURE 1
