Lennox SLP99DFV Series - Combustion Air Inducer; Cold End Header Box; Vent Pipe Assembly

Page 35
CAI Embossment
Intake Air Coupling
Clamp
Tubing
Exhaust Elbow
Exhaust Coupling
Blower Deck Seal
Pipe Clamp
Exhaust Pipe
Intake Air Pipe
Cold End Header Box
Combustion Air Inducer (CAI)
Exhaust Connector
with Alignment Tabs
Drain Cap
Combustion Air Inducer / Cold End Header Box / Vent Pipe Assembly
FIGURE 19
