BLOWER DATA
SLP99DF070XV36B BLOWER PERFORMANCE (less lter)
HEATING BLOWER PERFORMANCE - 0 through 0.8 in. w.g. External Static Pressure Range
Heating Adjust CFM Selections
Heating Input Range and Blower Volume - CFM
35% 40% 50% 60% 70% 80% 90% 100%
Increase (+15%) Heat CFM 495 543 639 735 830 926 1022 1118
Increase (+7.5%) Heat CFM 473 516 604 691 778 866 953 1041
Default Heat CFM 450 489 568 647 726 805 884 963
Decrease (-7.5% ) Heat CFM 430 467 540 614 687 761 834 908
Decrease (-15% ) Heat CFM 410 444 512 580 649 717 785 853
COOLING BLOWER PERFORMANCE - 0 through 1.0 in. w.g. External Static Pressure Range
Cooling Adjust CFM
Selections
Blower Speed Selections
First Stage Cool Speed - cfm Second Stage Cool Speed - cfm
Low Medium-
Low
Medium
High
High
(Default)
Low Medium-
Low
Medium
High
High
(Default)
Increase (+10%) Cool CFM 625 785 890 995 910 1075 1230 1365
Default Cool CFM 575 710 830 890 845 960 1125 1265
Decrease (-10%) Cool CFM 520 615 710 820 755 885 985 1150
The e󰀨ect of static pressure is included in air volumes shown.
The following control congurations are available. See Installation Instructions for details and DIP switch settings.
Heat Modes Available (Heating Blower Performance Table):
Single-stage thermostat:
- 35%, 70%, 100% input (three-stage) with time delays in-between
Two-stage thermostat:
- Variable Rate Capacity Mode - furnace automatically adjusts ring rate based on rst- and second-stage cycle times.
- W1 demand at 70% input, W2 demand at 100% input. No delay between stages.
Cool Mode Available (Cooling Blower Performance Table):
First stage COOL (two-stage air conditioning units only) is approximately 70% of the same second stage COOL speed position.
Continuous Fan speeds are approximately 28% and 38% (DIP switch selectable) of the same second-stage COOL speed position minimum 250 cfm.
Lennox iHarmony
®
Zoning System Applications - Minimum blower speed is 250 cfm.
SLP99DF070XV36B BLOWER MOTOR WATTS - COOLING
Blower Speed
Options
Motor Watts @ Various External Static Pressures - in. wg.
First Stage Second Stage
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Increase (+10%) Cool CFM
Low 20 37 57 71 90 108 128 142 162 67 90 110 136 159 184 200 226 252 271 292
Medium-Low 36 59 77 96 125 145 166 187 203 113 136 164 188 223 256 276 309 332 354 367
Medium-High 59 82 104 132 151 178 199 222 244 185 199 239 270 297 331 356 393 411 430 441
High 83 107 135 158 185 213 247 258 286 279 292 323 359 387 417 445 475 500 515 509
Default Cool CFM
Low 18 29 51 66 83 98 111 127 143 48 66 84 118 141 164 185 203 226 243 260
Medium-Low 27 50 64 84 105 124 146 162 185 89 109 142 160 188 211 240 262 286 312 327
Medium-High 39 60 81 109 136 162 183 194 220 126 145 183 209 244 272 301 330 358 378 401
High 65 82 112 144 164 185 207 227 257 209 218 261 292 320 352 384 400 424 448 462
Decrease (-10%) Cool CFM
Low 11 28 39 57 74 89 102 116 137 36 55 74 91 120 137 160 183 198 213 233
Medium-Low 23 37 57 77 92 112 128 143 156 63 83 105 132 162 181 208 227 251 268 291
Medium-High 32 54 70 87 113 133 149 172 189 90 112 144 164 200 216 246 275 303 326 342
High 47 67 91 115 139 163 184 203 224 134 151 192 222 255 287 320 348 370 395 414
