BLOWER DATA
SLP99UH135XV60D BLOWER PERFORMANCE (less lter)
SINGLE SIDE RETURN AIR − Air volumes in bold require Optional Return Air Base and eld fabricated transition to accommodate
20 x 25 x 1 in. air lter in order to maintain proper air velocity.
HEATING BLOWER PERFORMANCE - 0 through 0.8 in. w.g. External Static Pressure Range
Heating Adjust CFM Selections
Heating Input Range and Blower Volume - CFM
35% 40% 50% 60% 70% 80% 90% 100%
Increase (+15%) Heat CFM 927 1010 1175 1340 1505 1671 1836 2001
Increase (+7.5%) Heat CFM 844 923 1081 1239 1398 1556 1714 1873
Default Heat CFM 760 836 987 1138 1290 1441 1593 1744
Decrease (-7.5% ) Heat CFM 703 775 919 1064 1208 1352 1496 1641
Decrease (-15% ) Heat CFM 646 715 852 989 1126 1263 1400 1537
COOLING BLOWER PERFORMANCE - 0 through 1.0 in. w.g. External Static Pressure Range
Cooling Adjust CFM
Selections
Blower Speed Selections
First Stage Cool Speed - cfm Second Stage Cool Speed - cfm
Low Medium-
Low
Medium
High
High
(Default)
Low Medium-
Low
Medium
High
High
(Default)
Increase (+10%) Cool CFM 1070 1235 1385 1535 1550 1720 1925 2005
Default Cool CFM 985 1110 1245 1395 1415 1605 1755 1970
Decrease (-10%) Cool CFM 870 1010 1110 1260 1280 1435 1610 1755
The e󰀨ect of static pressure is included in air volumes shown.
The following control congurations are available. See Installation Instructions for details and DIP switch settings.
Heat Modes Available (Heating Blower Performance Table):
Single stage thermostat:
- 35%, 70%, 100% input (three-stage) with time delays in-between.
Two-stage thermostat:
- Variable Rate Capacity Mode - furnace automatically adjusts ring rate based on rst- and second-stage cycle times.
- W1 demand at 70% input, W2 demand at 100% input. No delay between stages.
Cool Mode Available (Cooling Blower Performance table):
First stage COOL (two-stage air conditioning units only) is approximately 70% of the same second stage COOL speed position.
Continuous Fan speeds are approximately 28% and 38% (DIP switch selectable) of the same second-stage COOL speed position.
minimum 380 cfm.
Lennox iHarmony
®
Zoning System Applications - Minimum blower speed is 450 cfm.
