Lennox SPB036H4

SPB − 3 to 5 Ton R−410A Heat Pump Outdoor Units / Page 8
DIMENSIONS − INCHES (MM)
ELECTRICAL
INLETS
SIDE VIEW
DISCHARGE AIR
VAPOR LINE
CONNECTION
LIQUID LINE
CONNECTION
A
BC
4−1/4(108)
4−3/4
(121)
1 (25)
2 (51)
END VIEW
TOP VIEW
VAPOR LINE
CONNECTION
LIQUID LINE
CONNECTION
UNIT SUPPORT
FEET
8−1/2
(216)
SPB036H4 T0 SPB048H4 BASE SECTION
8−3/4
(222)
5−1/2
(140)
9−1/2
(241)
8−1/4
(210)
13−1/2
(343)
UNIT SUPPORT
FEET
SPB060H4 BASE SECTION
16−7/8
(429)
4−5/8
(117)
26−7/8
(683)
8−3/4
(222)
30−3/4
(781)
3−3/4
(95)
3−1/8
(79)
Model No
A B C
M
o
d
e
l
N
o.
in.
mm in. mm in. mm
SPB036H4
35 889 30−1/2 775 35 889
SPB048H4 45 1143 30−1/2 775 35 889
SPB060H4 39 991 35−1/2 902 39−1/2 1003
