XC17 - 2 to 5 Ton Air Conditioner / Page 9
LENNOX
®
SOLAR SUBPANEL - OUTDOOR UNIT USAGE
Outdoor Unit Model No.
Lower Subpanel Height - in. (mm)
21 (533) 27 (686)
XC17-024 X
XC17-030-036-042-048-060 X
SUNSOURCE
®
HOME ENERGY SYSTEM - COMPONENTS
Description Catalog Number
OUTDOOR UNIT COMPONENTS
Lennox
®
Solar Subpanel
(see table below for lower subpanel usage)
67W83
SOLAR COMPONENTS
Solar Module (4-pack)
175 W, single-phase 240 VAC. Weight - 46 lbs. (each module)
Y3303
Dimensions (L x W x D)
62-5/8 x 32-1/4 x 2-3/4 in. (1590 x 819 x 70 mm)
ROOF MOUNTING KITS FOR SOLAR MODULES (Kits contain enough hardware for mounting four solar modules)
Composition (Asphalt) Shingle Y3306
Flat (Cement) Tile Y3307
S or Barrel Tile Y3308
Standing Seam Y3309
INSTALLATION KITS AND TOOLS
AC System Kit (Required - One per each outdoor unit) Y3310
AC 6 Foot Extension Cable Y3313
Rooftop Junction Box Y3312
Professional Installer Tool Kit Y3314
Solar Module Splices (10-pack) Y3311
MONITORING CONTROLS
Envoy Communications Gateway Y3304
Communications Booster Y3305
