Lennox XP16 Series

Page 2
XP16
Model Number Identification
P 16 036
− −
Unit Type
P = Heat Pump
Series
Nominal Cooling Capacity
024 = 2 tons
036 = 3 tons
048 = 4 tons
060 = 5 tons
Minor Revision Number
230
Voltage
230 = 208/230V−1ph−60hz
Refrigerant Type
X = HFC−410A
X 5
−
Typical Serial Number Identification
19 09 C
Year Code
08 = 2008
09 = 2009
10 = 2010
Month Code
A = January
B = February
C = March
05716
5 (or 6) Digit Unique Number
Location Code
19 = Saltillo, Mexico
58 = Marshalltown, IA
Specifications
Model Number
Unit Outdoor Fan
Sound Rating Number
(dB)
1
Factory Refrigerant
Charge
2
Number of Blades Diameter − inches.
XP16−024−230−01 74 9 lbs. 9 oz. 3 18
XP16−024−230−03 74 7 lbs. 13 oz. 3 18
XP16−024−230−04 74 7 lbs. 13 oz. 3 18
XP16−024−230−05 74 8 lbs. 13 oz. 3 18
Model Number
Unit Outdoor Fan
Sound Rating Number
(dB)
1
Factory Refrigerant
Charge
2
Number of Blades Diameter − inches.
XP16−036−230−01 76 12 lbs. 8 oz. 4 22
XP16−036−230−02 76 12 lbs. 8 oz. 4 22
XP16−036−230−03 76 10 lbs. 4 oz. 4 22
XP16−036−230−04 76 10 lbs. 4 oz. 4 22
XP16−036−230−05 76 10 lbs. 9 oz. 4 22
Model Number
Unit Outdoor Fan
Sound Rating Number
(dB)
1
Factory Refrigerant
Charge
2
Number of Blades Diameter − inches.
XP16−048−230−01 76 15 lbs. 7 oz. 4 22
XP16−048−230−02 76 15 lbs. 7 oz. 4 22
XP16−048−230−03 76 15 lbs. 7 oz. 4 22
XP16−048−230−04 76 15 lbs. 7 oz. 4 22
XP16−048−230−05 76 11 lbs. 12 oz. 3 26
Model Number
Unit Outdoor Fan
Sound Rating Number
(dB)
1
Factory Refrigerant
Charge
2
Number of Blades Diameter − inches.
XP16−060−230−01 78 13 lbs. 8 oz. 3 26
XP16−060−230−02 78 13 lbs. 8 oz. 3 26
XP16−060−230−03 78 11 lbs. 7 oz. 3 26
XP16−060−230−04 78 11 lbs. 7 oz. 3 26
XP16−060−230−05 78 12 lbs. 15 oz. 3 26
1
Tested according to AHRI Standard 270−2008 test conditions.
2
Refrigerant charge sufficient for 15 feet length of refrigerant lines.
