SPECIFICATIONS
General
Dt
Model No. XP19−024 XP19−036 XP19−048 XP19−060
Data
Nominal Tonnage (kW) 2 (7.0)
3 (10.6) 4 (14.1) 5 (17.6)
Connections
(t)
Liquid line (o.d.) − in. (mm) 3/8 (9.5) 3/8 (9.5) 3/8 (9.5) 3/8 (9.5)
(sweat)
Vapor line (o.d.) − in. (mm) 7/8 (22.2)
7/8 (22.2) 7/8 (22.2) 1−1/8 (28.6)
Refrigerant
1
R−410A charge furnished 12 lbs. 0 oz. (5.4
kg)
12 lbs. 5 oz. (5.6
kg)
13 lbs. 8 oz. (6.1
kg)
16 lbs. 5 oz. (7.4
kg)
Outdoor
Cil
Net face area − sq. ft. (m2) Outer coil 20.50 (1.90) 20.50 (1.90) 26.92 (2.50) 26.92 (2.50)
Coil
Inner coil 19.86 (1.85)
19.86 (1.85) 26.07 (2.42) 26.07 (2.42)
Tube diameter − in. (mm) 5/16 (0.52) 5/16 (0.52) 5/16 (0.52) 5/16 (0.52)
No. of rows 2 2 2 2
Fins per inch (m) 22 (866) 22 (866) 22 (866) 22 (866)
Outdoor
F
Diameter − in. (mm) 26 (660) 26 (660) 26 (660) 26 (660)
Fan
No. of blades 3
3 3 3
Motor hp (W) 1/3 (249) 1/3 (249) 1/3 (249) 1/3 (249)
Cfm (L/s) 1st stage 2500 (1180) 2500 (1180) 2800 (1320) 2800 (1320)
2nd stage 2500 (1180) 2800 (1320) 3400 (1605) 3400 (1605)
Rpm − 1st stage 700 700 700 700
2nd stage 700 820 820 820
Watts − 1st stage 70 70 150 150
2nd stage 70 105 220 220
Shipping Data − lbs. (kg) 1 pkg. 304 (138) 315 (143) 352 (160) 387 (176)
ELECTRICAL DATA
Line voltage data − 60hz 208/230V−1ph 208/230V−1ph 208/230V−1ph 208/230V−1ph
3
Maximum overcurrent protection (amps) 25 40 50 60
2
Minimum circuit ampacity 15.7 23.7 29.3 34.9
Compressor
Rated load amps 10.3 16.7 21.2 25.7
p
Locked rotor amps 52 82 96 118
Power factor 0.98 0.98 0.98 0.98
Outdoor Coil
Fan Motor
Full load amps 2.8 2.8 2.8 2.8
OPTIONAL ACCESSORIES − must be ordered extra
Compressor Hard Start Kit
10J42  
p
81J69  
Compressor Low Ambient Cut−Off 45F08    
Freezestat
3/8 in. tubing 93G35    
1/2 in. tubing 39H29    
5/8 in. tubing 50A93    
Indoor Blower Relay 40K58    
Low Ambient Kit 68M04    
Monitor Kit − Service Light 76F53    
Mounting Base 69J07    
Outdoor
Th t t
Thermostat 56A87    
Thermostat
Kit
Mounting Box − US 31461    
Kit
Canada 33A09    
SignatureStatt Home Comfort Control 81M28    
Refrigerant
Line Sets
L15−65−15
L15−65−30
L15−65−40
L15−65−50
  
Field Fabricate 
Time Delay Relay 58M81    
NOTE − Extremes of operating range are plus 10% and minus 5% of line voltage.
1
Refrigerant charge sufficient for 15 ft. (4.6 m) length of refrigerant lines.
2
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
3
HACR type breaker or fuse.
