ZGB PLUMBING
EVAPORATOR
COIL
DRIER
COMPRESSOR
S4 HIGH
PRESSURE LIMIT
DISCHARGE
PRESSURE TAP
LIQUID
PRESSURE TAP
FIXED ORIFICE
REFRIGERANT
METERING
DEVICE (RFC)
CONDENSER COIL
SUCTION
PRESSURE TAP
FIGURE 5
