Page 18
ZH 036, 048, 060
TABLE 5
ZHA048 NORMAL OPERATING PRESSURES
Outdoor Coil Entering Air Temperature
65 F 75 F 85 F 95 F 105 F 115 F
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
113 253 116 293 119 336 122 383 125 435 128 492
121 258 123 297 126 341 129 387 133 440 137 498
133 267 138 308 143 354 146 401 151 459 154 516
140 273 148 317 155 366 161 418 167 475 172 536
TABLE 6
ZHA060 NORMAL OPERATING PRESSURES
Outdoor Coil Entering Air Temperature
65 F 75 F 85 F 95 F 105 F 115 F
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
113 254 115 292 119 335 122 380 125 430 128 487
121 260 123 299 126 343 130 391 134 440 137 496
130 265 138 308 143 354 147 404 151 456 154 513
136 270 145 315 153 364 160 414 167 471 172 529
TABLE 7
ZHB036 NORMAL OPERATING PRESSURES
Outdoor Coil Entering Air Temperature
65 F 75 F 85 F 95 F 105 F 115 F
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
119 236 122 274 125 315 128 361 130 410 133 464
126 239 128 278 132 320 136 366 138 416 141 471
135 245 144 285 151 330 153 380 158 429 161 487
140 250 151 290 159 335 167 385 174 440 178 498
TABLE 8
ZHB048 NORMAL OPERATING PRESSURES
Outdoor Coil Entering Air Temperature
65 F 75 F 85 F 95 F 105 F 115 F
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
116 248 119 287 121 328 123 374 126 423 128 477
123 252 127 292 129 336 132 382 135 433 137 487
133 260 140 302 145 347 148 395 152 451 156 505
137 264 146 308 154 357 162 409 168 464 173 523
TABLE 9
ZHB060 NORMAL OPERATING PRESSURES
Outdoor Coil Entering Air Temperature
65 F 75 F 85 F 95 F 105 F 115 F
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
114 255 118 297 120 338 123 387 126 433 130 487
121 257 125 298 131 350 131 389 134 443 137 504
131 267 138 311 144 362 148 410 152 457 153 524
137 269 143 315 154 364 162 417 167 474 169 534
