What to do if Lenovo D27-30 Monitor power indicator is not lit?
If the Lenovo Monitor's power indicator isn't lit and there's no image, ensure the power cord is properly connected and the outlet has power. Also, power on the monitor. If it still doesn't work, try another power cord or electrical outlet. The issue might be due to the monitor’s power switch not being on, a loose or disconnected power cord, or a lack of power at the outlet.
How to improve Lenovo D27-30 image quality?
If the image quality of your Lenovo Monitor is unacceptable, ensure the video signal cable is firmly plugged into both the system and the monitor. Also, select another colour setting from the OSD menu. Finally, perform automatic image setup, as the issue might be that it was not performed.
How to fix blurry image on Lenovo Monitor?
To fix a blurry image or fuzzy lines on your Lenovo Monitor, adjust the resolution settings on your system to match the native resolution for this monitor: 1920x1080 at 60 Hz. Also, perform automatic image setup; if that doesn't help, perform manual image setup. When working in the native resolution, you may find additional improvements by adjusting the Dots Per Inch (DPI) setting on your system. This issue can arise if image setup or your system's Display Properties settings haven't been optimized.
How to fix Lenovo D27-30 when it says 'Out of Range'?
If your Lenovo Monitor displays 'Out of Range' and the power indicator flashes white, it means the system is set to a display mode not supported by the monitor. If replacing an old monitor, reconnect the old one and adjust the display mode to the specified range for your new monitor. If using Windows, restart in safe mode and select a supported display mode. If these don't work, contact Customer Support.
How to fix Lenovo D27-30 Monitor image when switching to dual mode?
To fix an unacceptable image when switching your Lenovo Monitor to dual mode, use ThinkVision Duo software to optimize the dual-screen operation. Alternatively, adjust the graphic card resolution manually. This is likely due to not setting the optimum resolution for each mode.
Why are pixels discolored on my Lenovo D27-30?
Discolored pixels are a characteristic of LCD technology and not necessarily a defect. If there are more than five pixels missing, contact the Customer Support Centre.
General| Panel type | VA |
|---|---|
| Color depth | 8 bit |
| Pixel pitch | 0.3114 x 0.3114 mm |
| Aspect ratio | 4:3, 16:9 |
| Screen shape | Flat |
| Pixel density | 82 ppi |
| Backlight type | W-LED |
| Display surface | Matt |
| Display diagonal | 27 \ |
| Display technology | LED |
| Native aspect ratio | 16:9 |
| Maximum refresh rate | 75 Hz |
| Supported video modes | 720p, 1080p |
| NTSC coverage (typical) | 72 % |
| Viewable size, vertical | 336.31 mm |
| Contrast ratio (dynamic) | 3000000:1 |
| Contrast ratio (typical) | 3000:1 |
| Display number of colors | 16.78 million colors |
| Viewable size, horizontal | 597.89 mm |
| Display brightness (typical) | 250 cd/m² |
| Supported graphics resolutions | 1280 x 720 (HD 720), 1920 x 1080 (HD 1080) |
| AMD FreeSync | Yes |
| Compatible operating systems | Windows 7, Windows 10 |
| Certification | CCC |
| Product color | Black |
| Market positioning | Business |
| HDMI version | 1.4 |
| DisplayPorts quantity | 0 |
| Headphone connectivity | 3.5 mm |
| Tilt angle range | -5 - 22 ° |
| Cable lock slot type | Kensington |
| Panel mounting interface | 100 x 100 mm |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Energy efficiency scale | A to G |
| Power consumption (off) | 0.3 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (typical) | 22 W |
| Package type | Box |
| Package depth | 179 mm |
| Package width | 717 mm |
| Package height | 453 mm |
| Package weight | 6620 g |
| Cables included | AC, HDMI |
| HDMI cable length | 1.8 m |
| Sustainability certificates | RoHS |
Weight and Dimensions| Bezel width (side) | 1.8 mm |
|---|---|
| Depth (with stand) | 231.2 mm |
| Width (with stand) | 614.1 mm |
| Height (with stand) | 444.4 mm |
| Weight (with stand) | 4750 g |
| Bezel width (bottom) | 28.1 mm |
| Depth (without stand) | 43.7 mm |
| Height (without stand) | 375.4 mm |
| Weight (without stand) | 4040 g |
Lists items included in the product package.
Steps for connecting, powering on, and initial monitor setup.
Information on monitor adjustments, user controls, and cable lock slot.
Instructions and benefits of registering the Lenovo product.
Optimizing workspace, posture, and viewing for comfort and health.
Minimizing visual fatigue through environment, habits, and posture.
Adjusting blue light settings and accessing accessibility information.
Using direct access and OSD controls to adjust image settings.
Selecting display modes and understanding power saving features.
Crucial warnings for safe monitor operation and connection.
Guidelines for maintaining and cleaning the monitor safely.
Detailed technical specifications of the monitor.
Solutions for common monitor problems and error messages.
Guides for manual image setup and driver installation.
Details on warranty, customer duties, and getting help.
Accessing online and telephone technical support services.
Legal disclaimers, intellectual property, and trademarks.
Guidelines for recycling Lenovo monitors and components.
Important notes on using correct power cords and adapters.
