Chapter 2. 2-3
Adjusting your monitor image
This section describes the control features to adjust your monitor image.
Using the direct access controls
The direct access controls can be used when the On-Screen Display (OSD) is not displayed.
Icon Control Description
1
Switches the video input source
Input Source
Press and hold for 10 seconds to enable or disable the
Direct access to Mode Switch
DDC-CI
Mode Switch
DDC-CI function
Exit Exit and return to previous level
2
Decrease/Up
Up browsing key
For increasing the value on adjustment bar/tune in
Press to move to previous item
3
Brightness Direct access to Brightness adjustment
Down browsing key
Increase/Down For decreasing the value on adjustment bar/tune in
Press to move to next item
4
Menu
To access OSD menu
Press to confirm selection
Press and hold for 10 seconds will lock menu/un-
lock menu
Enter
Press to enter next level on main menu/sub menu
status or enter previous level on adjustment bar
Downloaded from www.vandenborre.be

Questions and Answers:

Lenovo G24-10 Specifications

General IconGeneral
3D-
Panel typeTN
Color gamut72 %
Pixel pitch0.2715 x 0.2715 mm
Screen shapeFlat
Pixel density93 ppi
Response time3 ms
Backlight typeW-LED
Display diagonal23.6 \
Native aspect ratio16:9
Viewable size, vertical293.22 mm
Viewing angle, vertical160 °
Contrast ratio (dynamic)3000000:1
Contrast ratio (typical)1000:1
Display number of colors16.78 million colors
Display brightness (peak)300 cd/m²
Viewable size, horizontal521.28 mm
Viewing angle, horizontal170 °
Display brightness (typical)240 cd/m²
Supported graphics resolutions1920 x 1080 (HD 1080)
AMD FreeSyncYes
Product colorBlack
Sustainability certificatesRoHS
HDMI version1.4
DisplayPort version1.2
VGA (D-Sub) ports quantity0
Tilt angle range-5 - 22 °
Cable lock slot typeKensington
Number of OSD languages8
Panel mounting interface100 x 100 mm
AC input voltage90 - 264 V
AC input frequency47/63 Hz
Power consumption (max)34 W
Power consumption (off)0.3 W
Power consumption (standby)- W
Power consumption (typical)21 W
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 95 %
Operating relative humidity (H-H)10 - 80 %
Package depth620 mm
Package width130 mm
Package height410 mm
Package weight4950 g
Cables includedAC, HDMI
Harmonized System (HS) code85285210
Weight and Dimensions IconWeight and Dimensions
Bezel width (top)19.13 mm
Bezel width (side)17.58 mm
Depth (with stand)190.49 mm
Width (with stand)557.2 mm
Height (with stand)419.34 mm
Bezel width (bottom)24.23 mm
Width (without stand)- mm
Weight (without stand)3730 g
