Lenovo IdeaCentre B310 - Left and Right Views of the Computer

3
User Guide
1.2 Left and right view of the computer
Attention: Be sure not to block any air vents on the computer. Blocked
air vents may cause thermal problems.
2
3
4
1
2
5
Memory card reader Microphone connector
USB connector Optical drive
Headphone connector
