Lenovo ThinkCentre M55p Hardware Maintenance Manual

DiagnosticErrorCodeFRU/Action
006-197-XXXDisketteinterfacetestwarning
1.Ifacomponentiscalledout,makesureitis
connectedand/orenabled
2.Re-runtest
3.Replacethecomponentthatiscalledoutinwarning
statement
4.Replacethecomponentundertest
006-198-XXXDisketteinterfacetestaborted
1.Ifacomponentiscalledout,makesureitis
connectedand/orenabled
2.Flashthesystemandre-test.See“Flashupdate
procedures”onpage375
3.Goto“Undeterminedproblems”onpage76
006-199-XXXDisketteinterfacetestfailed,cause
unknown
1.Goto“Undeterminedproblems”onpage76
2.Flashthesystemandre-test
3.Replacecomponentunderfunctiontest
006-25X-XXXDisketteinterfaceError
1.Diskettedrivecable
2.Diskettedrive
3.Systemboard
011-000-XXXSerialportInterfaceTestPassed
Noaction
011-001-XXXSerialportPresence
1.Removeexternalserialdevice,ifpresent
2.Runsetup,enableport
3.Systemboard
011-002-XXX011-003-XXXSerialportTimeout/Parity
error
Systemboard
011-013-XXX011-014-XXXSerialportControl
Signal/Loopbacktestfailure
Systemboard
011-015-XXXSerialportExternalLoopbackfailure
1.Wrapplug
2.Systemboard
011-027-XXXSerialportConguration/Setuperror1.RunSetup,enableport
2.Flashthesystem.See“Flashupdateprocedures”on
page375
3.Systemboard
011-03X-XXX011-04X-XXXSerialportfailureSystemboard
011-195-XXXSerialportTestabortedbyuser
InformationonlyRe-startthetest,ifnecessary
011-196-XXXSerialporttesthalt,errorthreshold
exceeded
1.PressF3toreviewthelogle
2.Re-startthetesttoresetthelogle
011-197-XXXSerialporttestwarning
1.Makesurethecomponentthatiscalledout
isconnectedand/orenabled.SeeChapter6
“Diagnostics,TestandRecoveryInformation”on
page47
2.Re-runtest
3.Replacethecomponentthatiscalledoutinwarning
statement
4.Replacethecomponentundertest
58HardwareMaintenanceManual
