Lenovo ThinkCentre M55p Hardware Maintenance Manual

DiagnosticErrorCodeFRU/Action
020-196-XXXPCItesthalt,errorthresholdexceeded
1.PressF3toreviewthelogle
2.Re-startthetesttoresetthelogle
020-197-XXXPCItestwarning
1.Makesurethecomponentthatiscalledout
isconnectedand/orenabled.SeeChapter6
“Diagnostics,TestandRecoveryInformation”on
page47
2.Re-runtest
3.Replacethecomponentthatiscalledoutinwarning
statement
4.Replacethecomponentundertest
020-198-XXXPCItestaborted
1.Ifacomponentiscalledout,makesureitis
connectedand/orenabled.SeeChapter6
“Diagnostics,TestandRecoveryInformation”on
page47
2.Flashthesystemandre-test.See“Flashupdate
procedures”onpage375
3.Goto“Undeterminedproblems”onpage76
020-199-XXXPCItestfailed,causeunknown1.Goto“Undeterminedproblems”onpage76
2.Flashthesystemandre-test.See“Flashupdate
procedures”onpage375
3.Replacecomponentunderfunctiontest
020-262-XXXPCIsystemerror1.PCIcard
2.Risercard,ifinstalled
3.Systemboard
025-000-XXXIDEinterfaceTestPassed
Noaction
025-00X-XXX025-01X-XXXIDEinterfacefailure
1.IDEsignalcable
2.Checkpowersupplyvoltages
3.ReseatIDEsignalcable
4.IDEdevice
5.Systemboard
025-027-XXXIDEinterfaceConguration/Setuperror
1.IDEsignalcable
2.Flashthesystem.See“Flashupdateprocedures”on
page375
3.ReseatIDEsignalcable
4.IDEdevice
5.Systemboard
025-02X-XXX025-03X-XXX025-04X-XXXIDEInterface
failure
1.IDEsignalcable
2.Checkpowersupply
3.ReseatIDEsignalcable
4.IDEdevice
5.Systemboard
025-195-XXXIDEinterfaceTestabortedbyuserInformationonlyRe-startthetest,ifnecessary
025-196-XXXIDEinterfacetesthalt,errorthreshold
exceeded
1.PressF3toreviewthelogle
2.Re-startthetesttoresetthelogle
62HardwareMaintenanceManual
