DiagnosticErrorCodeFRU/Action
170-197-XXXVoltageSensor(s)testwarning
1.Makesurethecomponentthatiscalledout
isconnectedand/orenabled.SeeChapter6
“Diagnostics,TestandRecoveryInformation”on
page47
2.Re-runtest
3.Replacethecomponentthatiscalledoutinwarning
statement
4.Replacethecomponentundertest
170-198-XXXVoltageSensor(s)testaborted
1.Ifacomponentiscalledout,makesureitis
connectedand/orenabled.SeeChapter6
“Diagnostics,TestandRecoveryInformation”on
page47
2.Flashthesystemandre-test.See“Flashupdate
procedures”onpage375
3.Goto“Undeterminedproblems”onpage76
170-199-XXXVoltageSensor(s)testfailed,cause
unknown
1.See“Undeterminedproblems”onpage76
2.Flashthesystemandre-test.See“Flashupdate
procedures”onpage375
3.Replacecomponentunderfunctiontest
170-250-XXX170-251-XXXVoltageSensor(s)Voltage
limiterror
1.Powersupply
2.Systemboard
170-254-XXXVoltageSensor(s)VoltageRegulator
Moduleerror
1.VoltageRegulatorModule(VRM)
2.Microprocessor
3.Systemboard
175-000-XXXThermalSensor(s)TestPassed
Noaction
175-0XX-XXXThermalSensor(s)failure
1.Flashsystem
2.Systemboard
175-195-XXXThermalSensor(s)Testabortedbyuser
InformationonlyRe-startthetest,ifnecessary
175-196-XXXThermalSensor(s)testhalt,errorthreshold
exceeded
1.PressF3toreviewthelogle
2.Re-startthetesttoresetthelogle
175-197-XXXThermalSensor(s)testwarning
1.Makesurethecomponentthatiscalledout
isconnectedand/orenabled.SeeChapter6
“Diagnostics,TestandRecoveryInformation”on
page47
2.Re-runtest
3.Replacethecomponentthatiscalledoutinwarning
statement
4.Replacethecomponentundertest
175-198-XXXThermalSensor(s)testaborted
1.Ifacomponentiscalledout,makesureitis
connectedand/orenabled
2.Flashthesystemandre-test.See“Flashupdate
procedures”onpage375
3.Goto“Undeterminedproblems”onpage76
68HardwareMaintenanceManual
