10. Pivot the keyboard slightly upward as shown by arrow 1 . Then turn the keyboard over as shown by
arrow
2 .
11. Put the keyboard on the palm rest as shown and detach the connectors. Then remove the keyboard.
Chapter 6. CRU replacement 55
