Lenovo ThinkPad X1 Yoga Gen 8 Hardware Maintenance Manual

Chapter 7. FRU replacement notices
Read this chapter carefully before replacing any FRU.
Service tool kit
Ensure that the following service tool kit is prepared before you service a notebook computer.
No. Tool name Tool type
1 Phillips-head screwdriver Common tool
2
Conductive tweezers Common tool
3
Silicone grease Consumable tool
4 Polyamide tape
Consumable tool
5
Mylar tape Consumable tool
6 Eraser
Consumable tool
7
Electrical tape
Consumable tool
8 Double-sided tape
Consumable tool
9
Conductive tape Consumable tool
10
Trackpad jig (this might come with trackpad) Consumable tool
Note: The silicone grease can be applied to the surfaces of the microprocessor and heatsink to eliminate air
gaps.
Screw notices
Loose screws can cause a reliability problem. In your computer, this problem is addressed with special
nylon-coated screws that have the following characteristics:
• They maintain tight connections.
• They do not easily come loose, even with shock or vibration.
• They are harder to tighten.
Do the following when you service the computer:
• Keep the screw kit in your tool bag. For the part number of the screw kit, go to:
https://support.lenovo.com/partslookup
Tighten screws as follows:
• Plastic to plastic
Turn an additional angle of 90 degrees after the screw head touches the surface of the plastic part.
© Copyright Lenovo 2023 57

Lenovo ThinkPad X1 Yoga Gen 8 Specifications

General

Memory	Up to 32GB LPDDR5
Weight	Starting at 1.38 kg (3.04 lbs)
Operating System	Windows 11 Pro
Audio	Dolby Atmos Speaker System
Processor	13th Gen Intel Core i7
Display	14" 2.8K (2880 x 1800) OLED, 400 nits
Display Option	Touchscreen
Graphics	Intel Iris Xe Graphics
Storage	Up to 2TB PCIe SSD
Battery	57Wh
Ports	2x Thunderbolt 4, 2x USB-A 3.2 Gen 1, HDMI 2.1, headphone/mic combo jack
Connectivity	Wi-Fi 6E, Bluetooth 5.2
Camera	FHD 1080p with ThinkShutter
Security	Fingerprint reader, dTPM 2.0
