Lenovo ThinkPad X1 Yoga Gen 8 Hardware Maintenance Manual

Removal steps of the LCD unit (for ThinkPad X1 Carbon Gen 11)
Step Screw (quantity) Color
Torque
4
M2.5 × L3.5 mm, flat-head, nylon-coated (4) Black 0.294 Nm
(3.0 kgf-cm)
1190 Keyboard bezel assembly with keyboard
To remove the keyboard bezel assembly, remove these FRUs in order:
• “1010 Base cover assembly” on page 64
• “1020 Built-in battery” on page 66
• “1030 M.2 SSD, bracket, and thermal pad” on page 67
• “1040 Wireless WAN card and bracket (for selected models)” on page 68
• “1050 Pen charger (for ThinkPad X1 Yoga Gen 8 only)” on page 70
• “1060 Pen holder (for ThinkPad X1 Yoga Gen 8 only)” on page 71
90
ThinkPad X1 Carbon Gen 11 and X1 Yoga Gen 8 Hardware Maintenance Manual

Lenovo ThinkPad X1 Yoga Gen 8 Specifications

General

Memory	Up to 32GB LPDDR5
Weight	Starting at 1.38 kg (3.04 lbs)
Operating System	Windows 11 Pro
Audio	Dolby Atmos Speaker System
Processor	13th Gen Intel Core i7
Display	14" 2.8K (2880 x 1800) OLED, 400 nits
Display Option	Touchscreen
Graphics	Intel Iris Xe Graphics
Storage	Up to 2TB PCIe SSD
Battery	57Wh
Ports	2x Thunderbolt 4, 2x USB-A 3.2 Gen 1, HDMI 2.1, headphone/mic combo jack
Connectivity	Wi-Fi 6E, Bluetooth 5.2
Camera	FHD 1080p with ThinkShutter
Security	Fingerprint reader, dTPM 2.0
