6.Installaninnerrailonthetwomountingstudsononesideoftheserverandthenslidetheinnerrailto
thebackoftheserveruntilitsnapsintoposition.InstalltwoM4x4screwstosecuretheinnerrailonthe
sideoftheserver.Then,installtheotherinnerrailtotheothersideoftheserverinthesameway.
Note:Notetheorientationoftheinnerrails.
Figure8.Installingtheinnerrailstobothsidesoftheserver
Figure9.Installingtheinnerrailstobothsidesoftheserver(sideview)
1Mountingstudholes(2)
2Innerrail
3Screwholes(2)
8
