7.Onafrontmountingangeoftherackcabinet,selectaproperrackmountingareafortheserver.Then,
positionthefrontmountingbracket1ofanouterrailontheinsideoftherackmountingarea2.
Note:Theholesinamountingangearedividedintogroupsbymeasuringmarks.Thethreeholes
betweentwoadjacentmeasuringmarksformagroup,whichindicates1Uspace.Notethemeasuring
marksonamountingangetohelpyoucorrectlyselectarackmountingareafortheserver.Formore
informationabouttheplacementoftheholesinamountingange,refertothedocumentationthat
comeswiththerackcabinet.
Figure10.Positioningthefrontmountingbracketoftheouterrailontheinsideoftherackmountingarea
9
