Lenovo ThinkServer RD330 Quick Manual

THE LENOVO® THINKSERVER® RD330
OS SUPPORT CPU
Microso Windows Server 2012 (Essentials / Standard / Datacenter)
Windows Server 2008 -- x86 Edition (Standard / Enterprise / Datacenter)
Windows Server 2008 -- x64 Edition (Standard / Enterprise / Datacenter)
Windows Server 2008 R2 -- x64 Edition (Standard / Enterprise / Datacenter)
Windows Server 2008 R2 SP1 -- x64 Edition (Standard / Enterprise / Datacenter)
Windows Small Business Server 2011(Standard / Premium Add On)
Novel SUSE Linux Enterprise Server (11.1 / 11.2)
RedHat Enterprise Linux Server (5.7 / 6.1)
VMWare vSphere (5.0 / 5.1) and VMWare ESXi
Microso Hyper-v Server 2008
Microso Hyper-v Server 2008 R2 with SP1
Dual socket.
Intel Xeon E5-2400 series, up to 95W choices
STORAGE CHIPSET POWER
4x 3.5” HS HDD Bays – up to 12TB internal
SATA storage or 2.4TB internal SAS
storage
6x 2.5” HS HDD Bays – up to 6TB internal
SAS storage
Intel C600 1+1 Redundant Power – 550W (80Plus Gold),
Energy Star Server 1.1 compliant
MEMORY STORAGE CONTROLLER I/O CONNECTORS
12 DIMM sockets - up to 192GB
- RDIMM and LV RDIMM DDR3-1333
Memory DIMM
- 2G/4G/8G/16G RDIMM
- 2G/4G/8G/16G LV RDIMM
RAS: ECC, Lock step, Mirroring, Sparing
ThinkServer RAID 300 adapter (RAID
0/1/10)*
Optional RAID 300 Upgrade Key (RAID 5)
ThinkServer RAID 500 Adapter: Hardware
SAS/SATA supports RAID 0,1,10
Optional ThinkServer RAID 500 RAID 5
upgrade Key
ThinkServer RAID 700 Adapter: Hardware
SAS/SATA supports RAID 0/1/5/10/6/50/60
has 512MB cache
Optional ThinkServer RAID 700 battery
The following RAID components are available
configure to order:
Optional ThinkServer RAID 710 Adapter
Hardware SAS/SATA RAID supports RAID
0/1/5/10/6/50/60 has 1GB cache
Optional ThinkServer RAID Super Capacitor
Module
Optional ThinkServer RAID FastPath
Soware Key
Optional ThinkServer RAID CacheCade Pro
2.0 Key
Dual ports 10/100/1000 Intel i350 PHYs
One dedicated/shared management LAN
(Intel 82574)
Front: 2x USB2.0, 1x VGA
Rear: VGA, COM, 4x USB2.0,
Internal: 2x USB(2x5), 2x USB(typeA),
1x TPM/TCM
NETWORKING EXPANSION COOLING DIAGNOSTICS
The following networking components are
available configure to order. See Options
page for complete details.
* Optional single port, dual port and quad
port fibre channel HBA card choices by
Emulex and QLogic.
* Optional 10Ggbps ethernet server
adapter choices from Intel.
6 fixed fans Intelligent Diagnostics Panel
MANAGEABILITY/RAS/SERVICE I/O EXPANSION SLOTS DIMENSIONS /WEIGHTS/ CHASSIS
Optional Remote Management / KVM
IPMI 2.0 / SOL
TPM (Supports TCG 1.2)
uEFI
* IPMI 2.0 compliant / SOL
PCIe GEN3: 1 x LP x8 mechanical, x8 electrical
PCIe GEN3: 1 x FH/HL x16 mechanical, x16
electrical
436mm (W) x 43.6mm (H) x 720.6mm (D)
Max 17kg
1U Rack mountable
SPECIFICATIONS
* ThinkServer RAID 300 supports up to 8 HDDs.

Lenovo ThinkServer RD330 Specifications

General

Bus type	QPI
Stepping	M1
FSB Parity	No
Scalability	2S
Processor code	SR0LR
Processor cache	10 MB
Processor cores	4
Processor model	E5-2407
System bus rate	6.4 GT/s
Processor series	Intel Xeon E5-2400
Processor socket	LGA 1356 (Socket B2)
Processor codename	Sandy Bridge EN
Motherboard chipset	Intel® C606
Processor frequency	2.2 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor package size	45 x 42.5 mm
Processor front side bus	- MHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Supported instruction sets	AVX
Thermal Design Power (TDP)	80 W
Number of processors installed	1
Maximum number of SMP processors	2
Maximum number of PCI Express lanes	24
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25 GB/s
Maximum internal memory supported by processor	375 GB
HDD size	3.5 \
HDD interface	Serial ATA, Serial Attached SCSI (SAS)
Optical drive type	DVD-RW
Total storage capacity	0 GB
Maximum storage capacity	12 TB
Number of HDDs installed	0
Memory slots	12
Internal memory	4 GB
Memory clock speed	1333 MHz
Maximum internal memory	192 GB
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
PS/2 ports quantity	-
USB 2.0 ports quantity	6
Ethernet LAN (RJ-45) ports	3
Compatible operating systems	Windows Server 2012\\r Windows Server 2008\\r Windows Server 2008 R2\\r Windows Small Business Server 2011\\r Novel SUSE Linux Enterprise Server\\r VMware vSphere and VMware ESXi
Chassis type	Rack (1U)
Power supply	550 W
Sustainability certificates	ENERGY STAR
PCI Express slots version	3.0
Processor ARK ID	64614
Intel Identity Protection Technology version	0.00

Weight and Dimensions

Depth	734 mm
Width	482.4 mm
Height	43.6 mm
Weight	17000 g
